How to seal CAD multi-line

coldplay.xixi
coldplay.xixiOriginal
2021-01-27 10:40:5722406browse

How to seal multi-line in CAD: First open the multi-line style dialog box and select the Modify button; then check the small boxes of the starting point and end point behind the straight line; finally click the OK button.

How to seal CAD multi-line

The operating environment of this article: Windows 7 system, autocad2020 version, Dell G3 computer.

CAD multi-line sealing method:

1. After opening the software, enter the shortcut key mls, click the second item and hit Enter,

How to seal CAD multi-line

2. Get the multi-line style dialog box, select the modify button,

How to seal CAD multi-line

3. Then the modify multi-line style dialog box appears, in Put a check mark in the small boxes for the starting point and endpoint behind the straight line, and then click OK.

How to seal CAD multi-line

4. Return to the multi-line style dialog box, and you can see the multi-line style in the preview. Both ends of the line have been sealed, then click the OK button,

How to seal CAD multi-line

5. Enter the ml shortcut key, and then hit Enter,

How to seal CAD multi-line

6. Then draw a multi-line and you can see that both ends of it are closed.

How to seal CAD multi-line
