How to draw small arrows in cad: first open the CAD software, click to open it in the file bar according to your needs; then open the orthogonal mode at the bottom of the page, enter the PL command in the command box, space; finally enter w space, specify the starting point width and end point width, and specify the specific formula.

How to draw small arrows in CAD

The operating environment of this article: Windows 7 system, autocad2020 version, Dell G3 computer.

How to draw small arrows in CAD:

1. First, we open our computer, find the CAD icon on the desktop, double-click to open it, and enter the CAD software page.

How to draw small arrows in CAD

#2. Then we create a new file, or click to open it in the file bar according to our own needs.

How to draw small arrows in CAD

3. In order to draw arrows conveniently, first turn on the orthogonal mode at the bottom of the page, then enter the PL command in the command box, a space, and then specify the starting point and "Specify next Starting point.

How to draw small arrows in CAD

4. Then enter w space, specify the starting point width and end point width, and specify the specific formula as shown in the figure.

How to draw small arrows in CAD

5. Return to the drawing interface, stretch left and right to adjust the length of the arrow. Click OK and then click the space bar to complete the arrow drawing.

How to draw small arrows in CAD
