How to convert pdf drawings into cad drawings

How to convert pdf drawings into cad drawings: first open the pdf file and open the CAD software; then click [Insert-OLE Object] and find the acrobat type file; then find the path location where the PDF file is saved; Finally the PDF file is opened and the prompt is inserted into the CAD work window.

The operating environment of this article: Windows7 system, autocad2020&&adobe acrobat professional version 7.0, Dell G3 computer.

How to convert pdf drawings into CAD drawings:

1. Open the pre-saved PDF file

2. Open the CAD software

3. In the CAD software, click "Insert" → "OLE Object" → find the acrobat type file.

#4. Find the path location where the PDF file is saved.

#5. The PDF file is opened, and the prompt will be inserted into the CAD working window.

#6. Save it in the CAD format in the CAD software.
