Lenovo bios Chinese and English comparison table

Lenovo BIOS Chinese and English comparison table:

Time/System Time time/system time

Date/System Date date /System Date

Level 2 Cache Level 2 Cache

System Memory System Memory

Video Controller Video Controller

Panel Type LCD Screen Model

Audio Controller Audio Controller

Modem Controller Modem

Primary Hard Drive Main Hard Drive

Modular Bay Module Bay

Service Tag Service Tag

Asset Tag Asset Tag

BIOS Version BIOS Version

Boot Order/Boot Sequence Boot Order (the order in which the system searches for operating system files)

Diskette Drive Floppy drive

Internal HDD Internal hard drive

Floppy device Floppy device

Hard-Disk Drive Hard-Disk Drive

USB Storage Device USB storage device

CD/DVD/CD-RW Drive optical drive

CD-ROM device optical drive

Modular Bay HDD modular hard drive

Cardbus NIC Cardbus bus network card

Onboard NIC Onboard Network Card

Boot POST The level of hardware check when performing power-on self-test (POST): set to MINIMAL (default setting), the power-on self-check will only be performed when BIOS is upgraded and the memory module is changed. Or the check is only performed when the previous power-on self-test has not been completed. Set to THOROUGH to perform a full set of hardware checks during power-on self-test.

Config Warnings Warning settings: This option is used to set whether to alarm when the system uses a lower voltage power adapter or other unsupported configurations. Set it to DISABLED to disable the alarm, and set it to ENABLED to enable the alarm.

Internal Modem Internal Modem: Use this option to enable or disable the built-in Modem. When disabled, the Modem is not visible in the operating system.

LAN Controller Network Controller: Use this option to enable or disable the PCI Ethernet controller. When disabled, the device is not visible to the operating system.

PXE BIS Policy/PXE BIS Default Policy

PXE BIS Policy: This option controls how the system handles (Boot IntegrityServices (BIS)) authorization requests when there is no authentication. The system can accept or reject BIS requests. When set to Reset, BIS will be reinitialized and set to Deny the next time the computer is started.

#MiniPCI Status

Mini PCI Device Status: Use this option to enable or disable the onboard PCI device when installing a Mini PCI device

Wireless Control: Use this Options can set the control method of MiniPCI and Bluetooth wireless devices. When set to "Application", the wireless device can be enabled or disabled through applications such as Quickset, and hotkeys are not available. When set to "Application", the wireless device can be enabled or disabled through applications such as Quickset or hotkeys. When set to Always Off the wireless device is disabled and cannot be enabled in the operating system.

Wireless Wireless devices: Use this option to enable or disable wireless devices. This setting can be changed in the operating system via Quickset or hotkeys. Whether this setting is available depends on the Wireless Control settings.

Serial Port Serial Port: This option can avoid device resource conflicts by reassigning the port address or disabling the port.

Infrared Data Port Infrared data port. Use this setting to avoid device resource conflicts by reassigning port addresses or disabling ports.

Parallel Mode Parallel mode. Control computer parallel port working mode: NORMAL (AT compatible) (normal standard parallel port), BI-DIRECTIONAL (PS/2 compatible) (bi-directional mode, allowing two-way communication between the host and peripherals) or ECP Extended Capabilities Ports, extended function ports) ( default).

Num Lock Digital lock. Set whether the digital light (NumLock LED) lights up when the system starts. Set to DISABLE to keep the digital light off, and to ENABLE to light up the digital light when the system starts.

Keyboard NumLock Keyboard NumLock: This option is used to set whether to prompt keyboard-related error messages when the system starts.

Enable Keypad Enable Keypad: Set to BY NUMLOCK to enable the numeric keypad when the NumLock light is on and no external keyboard is connected. Set to Only By Key to keep the embedded keypad disabled when the NumLock light is on.

External Hot Key External Hot Key: This setting allows you to use the keys on an external PS/2 keyboard in the same way as using the keys on your laptop. If you use an ACPI operating system, such as Win2000 or WinXP, keys cannot be used with a USB keyboard. Keys are only available from USB keyboards in pure DOS mode. Set to SCROLL LOCK (the default option) to enable this feature, and to NOT INSTALLED to disable it.

USB Emulation USB emulation: Use this option to use USB keyboard, USB mouse and USB floppy drive in operating systems that do not directly support USB. This setting is automatically enabled during BIOS startup. When this feature is enabled, the simulation continues when control is transferred to the operating system. Disabling this feature turns off the emulation when control is transferred to the operating system.

Pointing Device Pointing Device: When set to "SERIAL MOUSE, the external serial mouse is enabled and the integrated touchpad is disabled. When set to PS/2 MOUSE, if an external PS/2 mouse is connected, then Disables the integrated touchpad. When set to TOUCH PAD-PS/2 MOUSE (default setting), if an external PS/2 mouse is connected, you can switch between the mouse and touchpad. The change will take effect after the computer is restarted.

Video Expansion: Use this option to enable or disable video expansion, adjusting the lower resolution to a higher, normal LCD resolution.

Battery Battery

Battery Status Battery Status

Power Management Power Management

Suspend Mode Suspend Mode

AC Power Recovery AC power recovery: This option can reflect the computer's response when the AC power adapter is plugged back into the system.

Low Power Mode Low Power Mode: This option is used to set the power used when the system sleeps or shuts down.

Brightness Brightness: This option can set the brightness of the monitor when the computer is started. The default setting is half when the computer is powered by the power supply. The default setting is maximum when the computer is powered by the AC power adapter.

Wakeup On LAN Wake on LAN: This option setting allows the computer to wake up from hibernation when the network signal is connected. This setting has no effect on the standby state (Standby state). It can only wake up the standby state in the operating system. This setting is only available when the AC power adapter is connected Valid when.

Auto On Mod Automatic power-on mode: Note that if the AC power adapter is not connected properly, this setting will not take effect. This option can set the computer’s automatic power-on time. You can set the computer to automatically power on every day or only after Automatically boot on weekdays. The setting takes effect after the computer is restarted.

Auto On Time Automatic boot time: This option can set the time when the system automatically powers on. The time format is 24-hour format. Type the value or use the left and right keys Use the arrow keys to set values. The settings take effect after the computer is restarted.

Dock Configuration Dock Configuration

Docking Status Dock Status

Universal Connect Universal Interface: If the operation If the system is WinNT4.0 or earlier, this setting has no effect. If you often use more than one Dell (Dell Notebook Zone) docking station device and want to minimize the initial time when connecting to the docking station, set it to ENABLED (default setting). If you want the operating system to generate a new system settings file for each new docking device connected to the computer, set this to DISABLED.

System Security System Security

Primary PassWord Master Password

Admin PassWord Management Password

Hard-disk drive passWord(s) Hard drive password

PassWord Status Password status: This option is used to lock the system password when the Setup password is enabled. Set this option to Locked and enable Setup Password to prevent system passwords from being changed. This option can also be used to place passwords disabled by the user on system startup.

System Password System Password

Setup Password Setup Password

Post Hotkeys Self-test hotkeys: This option is used to specify what is displayed on the screen during power-on self-test (POST). Hotkey (F2 or F12).

Chassis Intrusion: This option is used to enable or disable the chassis anti-theft detection feature. When set to "Enable-Silent", if chassis intrusion is detected during startup, no warning message will be sent. When this option is enabled and the chassis cover is open, this field will display DETECTED.

Drive Configuration Drive Settings

Diskette Drive A: If a floppy drive is installed in the system, use this option to enable or disable the floppy disk drive

Primary Master Drive One main drive

Primary Slave Drive The first slave drive

Secondary Master Drive The second main drive

Secondary Slave Drive The second slave drive

IDE Drive UDMA UDMA-capable IDE drives: Use this option to enable or disable DMA transfers over the internal IDE hard disk interface.

Hard-Disk drive Sequence Hard-Disk drive sequence

System BIOS boot devices System BIOS boot sequence

USB device USB device

Memory Information Memory information

Installed System Memory System Memory: This option displays the size and model of the memory installed in the system

System Memory Speed ​​Memory Speed: This option displays the speed of the installed memory

System Memory Channel Mode Memory channel mode: This option displays the memory slot settings.

AGP Aperture AGP area memory capacity: This option specifies the memory value allocated to the video adapter. Some video adapters may require more memory than the default amount.

CPU information: CPU information

CPU Speed ​​CPU speed: This option displays the running speed of the central processor after startup

Bus Speed ​​Bus Speed: Displays the processor bus speed

Processor 0 ID Processor ID: Displays the type and model number of the processor

Clock Speed ​​Clock Frequency

Cache Size Cache Value: Displays the processor's L2 cache value

Integrated Devices(LegacySelect Options) Integrated Device

Sound Sound Settings: Use this option to enable or disable the audio controller

Network Interface Controller Network Interface Controller: Enable or disable the integrated network card

Mouse Port Mouse Port: Use this option to enable or disable the built-in PS/2 compatible mouse controller

USB Controller USB Controller: Use this option to enable or disable the onboard USB controller.

PCI Slots PCI slot: Use this option to enable or disable the onboard PCI card slot. When disabled, all PCI cards are unavailable and cannot be detected by the operating system.

Serial Port 1 Serial Port 1: Use this option to control the operation of the built-in serial port. When set to AUTO, if two devices are used on the same port address through the serial port expansion card, the built-in serial port automatically reassigns the available port addresses. The serial port uses COM1 first and then COM2. If both addresses have been assigned to a port, the port will be disabled.

Parallel Port Parallel Port: The built-in parallel port can be configured in this field

Mode Mode: When set to AT, the built-in parallel port can only output data to the connected device. When set to PS/2, EPP or ECP mode, the parallel port can input and output data. The three modes use different protocols and maximum data transfer rates. Maximum transfer rate PS/2.

How to enter the BIOS of Lenovo computers: Press the power button, press F2 after the word Lenovo appears on the screen. For some models, F2 is in the lower right corner of the button. You need to press and hold Fn in the lower left corner of the keyboard at the same time. button.
