Stack frame structure and function in Java virtual machine

In Java virtual machine (JVM), stack frame is the execution Basic data structures for Java methods. It holds the method's local variables, operand stack, and frame data, including the method's return address and the current program counter (PC).

Stack frame structure

Each stack frame contains the following parts:

• Local variable table:Storage Local variables of the method.
• Operand stack: Used to store operands and intermediate results.
• Frame data: Contains the method's return address, current PC and other data.

The role of stack frames

Stack frames play a vital role in the JVM:

• Storing local variables: It provides space for storing method local variables.
• Operand operations: The operand stack is used to perform operand operations such as addition, multiplication, and Boolean operations.
• Method call: Each method call will create a new stack frame to save the return address and parameters of the method.
• Exception handling: The stack frame contains exception handling information, which is used to trace back the call stack when an exception occurs.
• Garbage collection: Object references in stack frames can help the garbage collector identify and collect objects that are no longer needed.

Practical case

To show the practical application of stack frames, let us create a simple Java method:

public static int add(int a, int b) {
  int c = a + b;
  return c;
}

When executing this method, the JVM will create the following stack frame:

局部变量表：
  - a: 10
  - b: 20
  - c: 0

操作数堆栈：
  - 10
  - 20
  - (结果)

帧数据：
  - 返回地址: 方法调用者的返回地址
  - 当前 PC: 方法内的当前指令

This stack frame stores the values ​​of local variables a and b, as well as the values ​​in the operand stack used to calculate the result. intermediate value. When this method is executed, the JVM moves the operand stack and updates the local variable table based on the information in the stack frame.

Understanding the structure and function of stack frames is crucial for a deep understanding of the execution process of Java programs.
