How to set up router tandem

How to connect another router to the router

Connect the router to the wireless router, and set up the second router. There are two methods (provided that the first router has been set up):

The first method: dynamic IP mode (the first route is the master route, the second route is the slave route)

1. Plug in the slave router, do not connect to the main router LAN port first, and reset the slave router (restore to factory settings);

2. Connect the computer to any LAN port of the router and enter the setting page;

3. Set according to dynamic IP mode;

4. Then set the SSID, encryption method and password;

5. Save and restart;

6. After setting up, connect the network cable from the LAN port of the main router to the WAN port of the slave router.

Second method: Wireless AP method

1. First connect the computer to the LAN port of the slave router and change the IP address of the slave router. For example, most router addresses are 192.168.1.1. We only need to change the router IP address to 192.168.1.10;

2. Then turn off the DHCP function of the router in the settings;

3. Finally, connect the network cable from the main router to the LAN port of the slave router (any one will do). Note that it cannot be a WAN port.

How to set up wireless connections for 2 or more routers

Follow the basic settings for the first router, fill in the broadband account and password, and you can access the Internet after the setting is successful. Then get the second router.

The second router is to connect the signal of the first router through wireless bridge. This requires the following conditions:

1: Router B needs to support the wireless relay function or WDS function (the specific setting of wireless bridging depends on the setting instructions of the router, which varies by brand)

2: The IP segment of router B cannot be the same as the first one. For example, the management IP of router A is 192.168.1.1, then the management IP of router B must be changed to 192.168.2.1 or 192.168.3.1. In short, the third segment The IP cannot be the same. That is, the IP segments cannot be the same.

3: Router B wants to relay the signal of router A. The signal encryption mode of Router A cannot be mixed. The encryption mode must be fixed before the relay bridge can be connected, such as setting WPA2-PSK and AES mode encryption! This encryption mode is the most advanced. The wireless channel should also be fixed to one. Generally, channels 1, 6, and 11 are relatively stable.

In short, the main problem is on Router B. The specific settings of wireless bridging vary depending on the router brand, but the basic principle is the same, wireless name, wireless encryption mode and password, and wireless channel. These 3 If the sample data is filled in correctly in the wireless relay settings of Router B, you can bridge the signal of Router A! hope this helps!

How to connect two routers to each other to access the Internet

There are currently 5 households, that is, one line after the first route comes out and then enters the second route

Divide it into two again, the routing wiring method and settings.

Router 1 in this two route connection method provides three-layer services (physical,

Data link and network layer), and Router 1 is also a hub. Router 2 provides four

Layer service, that is, acting as a switch.

Router 2 can be treated as a hub, that is to say, there are 5 units in the room

The computers are actually under the jurisdiction of Router 1. Then the fixed

allocated from route 1

The IP address cannot be reassigned to Router 2 which is only used as a switch at the same time.

Solution: Method 1: Start the DHCP service of Router 1, then your room will get the route

The LAN IP address assigned to you by Router 1. Note that your Router 2 only acts as a

The role of the switch (you can change it to a switch and the effect will be the same) [Recommended method]

Method 2: Divide the IP address of Router 1 into two subnet segments (by setting the subnet

net mask), your route 2 belongs to the subnet of route 1, router 2 provides routing function,

DNS servers are recommended to be used by some large companies (it is not recommended to use routers as DNS servers).

connection method:

Two routers connected

Route No. 1 is used for dialing. Pull a line from the LAN port of Route No. 1 to Route No. 2 and plug in

In the LAN port of Router No. 2, do not plug it into the Ethernet port. The network segment of the host must be the same as Router No. 1

Never mind it, Route 2 is equivalent to a switch.

Summary: 1. In fact, the broadband router is just a switch without using the WAN port. You can directly

Use switch cascade.

2. Before connecting the second router to the network, modify its default LAN port IP address to prevent

Stop conflicting with the first LAN port IP address.

3. Connect a LAN of the second router to the LAN of the first router using a direct cable

port, connect the original computer and the new computer to the

of the second router using direct cables
