Introduction:
As the scale of enterprises gradually expands, workflow management becomes more and more complex. Traditional paper workflows can no longer meet efficient and accurate management needs. Building an online workflow management system based on WebMan (Web-based Management) technology has become the choice of more and more enterprises. This article will introduce how to use WebMan technology to build a powerful, easy-to-use online workflow management system, with relevant code examples. I hope this article can provide readers with some useful guidance to help you successfully implement online workflow management.

1. Requirements Analysis
Before building an online workflow management system, we must first fully analyze the system requirements. Determine the scope of functions that the system needs to support, and clarify the user's operating procedures and data storage requirements. On this basis, we can formulate the outline design and detailed design of the system.

2. Technology Selection
WebMan technology is a management technology designed for the Web environment. It has the advantages of cross-platform and ease of use. Based on demand analysis, we chose to use Node.js as the back-end development language, use the Express.js framework to build the server, and use the Mongoose library to operate the MongoDB database.

3. System Architecture Design
The architecture design of the online workflow management system includes front-end design and back-end design.

Front-end design:
The front-end is developed using HTML, CSS and JavaScript, combined with frameworks such as Bootstrap and React to achieve a user-friendly interface. By following web standards, we can achieve cross-browser and cross-device access.

Backend design:
The backend uses Node.js as the development language and Express.js as the web application framework. Use the Mongoose library to operate the MongoDB database. We can implement different business logic by defining routes and controllers, and interact with the database through the data model.

4. System Function Implementation
We focus on the implementation methods of several key functions for reference.

1. User authentication function:
User authentication is one of the basic functions of the online workflow management system. The code example is as follows:

const express = require('express');
const bcrypt = require('bcrypt');
const jwt = require('jsonwebtoken');
const User = require('../models/user');
const router = express.Router();

// 用户注册
router.post('/register', (req, res) => {
  const { username, password } = req.body;
  bcrypt.hash(password, 10, (err, hash) => {
    if (err) {
      res.status(500).json({ error: err });
    } else {
      const user = new User({
        username: username,
        password: hash,
      });
      user.save()
        .then(result => {
          res.status(201).json({ message: 'User created' });
        })
        .catch(err => {
          res.status(500).json({ error: err });
        });
    }
  });
});

// 用户登录
router.post('/login', (req, res) => {
  const { username, password } = req.body;
  User.findOne({ username: username })
    .then(user => {
      if (user) {
        bcrypt.compare(password, user.password, (err, result) => {
          if (err) {
            res.status(401).json({ message: 'Auth failed' });
          } else if (result) {
            const token = jwt.sign({ username: user.username }, 'secret', { expiresIn: '1h' });
            res.status(200).json({ message: 'Auth successful', token: token });
          } else {
            res.status(401).json({ message: 'Auth failed' });
          }
        });
      } else {
        res.status(404).json({ message: 'User not found' });
      }
    })
    .catch(err => {
      res.status(500).json({ error: err });
    });
});

module.exports = router;

2. Process management function:
Process management is one of the core functions of the online workflow management system. The code example is as follows:

const express = require('express');
const Workflow = require('../models/workflow');
const router = express.Router();

// 创建流程
router.post('/', (req, res) => {
  const { name, description } = req.body;
  const workflow = new Workflow({
    name: name,
    description: description,
  });
  workflow.save()
    .then(result => {
      res.status(201).json({ message: 'Workflow created' });
    })
    .catch(err => {
      res.status(500).json({ error: err });
    });
});

// 获取流程列表
router.get('/', (req, res) => {
  Workflow.find()
    .exec()
    .then(workflows => {
      res.status(200).json(workflows);
    })
    .catch(err => {
      res.status(500).json({ error: err });
    });
});

module.exports = router;

5. System deployment and optimization
When deploying the system, we must first consider the selection and configuration of the server. You can use the virtual machine or container service provided by the cloud service provider to deploy the system, or you can choose to build your own server for deployment. In addition, system performance optimization must be carried out, including cache optimization, database index optimization, etc.

6. Conclusion
The construction of an online workflow management system involves many aspects of knowledge and technology. This article introduces the construction method based on WebMan technology and gives some code examples. I hope that through the introduction of this article, readers can understand the development process and some key technical points of the online workflow management system, and be able to apply it in actual projects. Of course, there are still many details that need to be paid attention to during the actual development process, and readers need to make adjustments and improvements according to the actual situation. I wish you smooth development of the online workflow management system!
