How to use C++ to develop various main functions of embedded systems

How to use C to develop each main function of an embedded system

An embedded system is a computer system that implements specific functions on a specific hardware platform. It usually has a small size , low power consumption and high reliability characteristics. As a powerful programming language, C can well meet the needs of embedded system development. This article will introduce how to use C to develop each main function of an embedded system and give corresponding code examples.

  1. Input and output functions

Embedded systems often need to communicate with external devices, including sensors, actuators, user interfaces, etc. C provides rich input and output functions, which can be achieved by using the iostream library, gpio library, etc. The following is a simple example code that controls the LED on and off through the GPIO port:

#include <gpio.h>

int main() {
    gpio_init();
    gpio_set_direction(2, GPIO_OUTPUT);

    while (true) {
        gpio_set_level(2, HIGH);
        delay(1000);
        gpio_set_level(2, LOW);
        delay(1000);
    }

    return 0;
}
  1. Multi-threading and task scheduling

Embedded systems often need to process multiple tasks at the same time tasks, so multithreading and task scheduling are key features for developing embedded systems. C's thread library can easily create and manage multiple threads, and you can also use the task scheduler to control the execution order of threads. The following is a simple sample code that shows how to use multi-threading and task scheduling to achieve parallel execution of tasks:

#include <thread>
#include <iostream>

void task1() {
    std::cout << "This is task 1" << std::endl;
}

void task2() {
    std::cout << "This is task 2" << std::endl;
}

int main() {
    std::thread t1(task1);
    std::thread t2(task2);

    t1.join();
    t2.join();

    return 0;
}
  1. Memory Management

Resources of Embedded Systems Often very limited, so managing memory efficiently is very important. C provides rich memory management functions, including dynamic memory allocation, smart pointers, etc. The following is a simple sample code that shows how to use smart pointers to manage memory:

#include <memory>
#include <iostream>

int main() {
    std::shared_ptr<int> p1 = std::make_shared<int>(42);
    std::shared_ptr<int> p2 = p1;

    std::cout << *p1 << std::endl; // 输出 42
    std::cout << *p2 << std::endl; // 输出 42

    return 0;
}
  1. Embedded system driver development

Interacting with hardware in embedded systems Part of this is usually implemented through the driver. C can develop drivers by interacting with the operating system, including reading and writing registers, controlling peripherals, etc. through APIs provided by the operating system. The following is a simple sample code that controls the on and off of the LED through the API provided by the Linux kernel:

#include <iostream>
#include <fcntl.h>
#include <unistd.h>

int main() {
    int fd = open("/dev/led", O_WRONLY);

    if (fd < 0) {
        std::cout << "Open device failed" << std::endl;
        return -1;
    }

    unsigned char led_on = 1;
    unsigned char led_off = 0;

    write(fd, &led_on, sizeof(led_on));
    sleep(1);
    write(fd, &led_off, sizeof(led_off));

    close(fd);

    return 0;
}

Summary:

This article introduces how to use C to develop each main function of the embedded system. Including input and output functions, multi-threading and task scheduling, memory management and embedded system driver development. Through the flexible use of these functions, powerful, reliable and stable embedded systems can be developed more efficiently. Of course, the above are just simple examples. In actual development, corresponding modifications and optimizations need to be made according to specific needs.
