What is the shortcut key for cad cloud line

The cad cloud line shortcut key is revcloud. The method to modify the cloud line in CAD is: 1. Open the software and click the revision cloud icon, then click the starting point of the cloud line in the picture and drag the mouse to draw; 2. Draw some images in the diagram and then convert them into revision clouds.

The operating environment of this article: Windows 7 system, AutoCAD 2007 version, Dell G3 computer.

Recommended: "Programming Video"

In CAD, the shortcut key for revision cloud is revcloud. The steps to modify the cloud line in CAD are as follows:

1. First, open the software and click the revision cloud icon.

#2. Click to modify the cloud line, then click the starting point of the cloud line in the picture and drag the mouse to draw.

#3. The second method is to first draw some images in the diagram and then convert them into revision clouds. First, you need to draw a rectangle in the picture.

#4. After drawing, click the revision cloud, and then select the object in the command bar below.

#5. We choose to set the arc of the cloud line. The maximum arc of the arc can be set as desired. Then click "Style" to set the style.

# 6. The style is divided into ordinary style and hand-painted style. Normal is the width of the line, Bribery is the width of the start and end points. Choose a hand-drawn style.

#7. Then select the object and click on the rectangle we drew.

#8. In dynamic input, click "No", and then you can generate a revision cloud.

9. This is a well-drawn revision cloud.
