In-depth understanding of Java loaders

1. Classes and Class Loaders

Class loader: The first step in the loading phase, through the fully qualified name of a class To load the binary byte stream of this class into the jvm.

Classes and class loaders: The uniqueness of any class is determined by itself and the class loader that loads it. Whether two classes are equal depends on the premise that they are loaded by the same class loader.

The jvm virtual machine includes two class loaders: one is the startup class loader (Bootstrap ClassLoader), which is implemented in C; the other is all others implemented in java Class loader.

From a java program perspective:

1) Start the class loader: Responsible for loading classes in the \lib directory or in the path specified by the -Xbootclasspath parameter, in addition to requiring files The name is recognized by the virtual machine. If it is not recognized by the jvm, it cannot be loaded.

2) Extension class loader: Responsible for loading all class libraries in the \lib\exit directory or in the path specified by the java.exit.dirs system variable.

3) Application class loader (system class loader): It is the return value of the getSystemClassloader() method in Classloader. Responsible for loading the class library specified on the user class path. If there is no custom class loader in the application, this will be the default class loader in the program.

Free online video teaching: java video tutorial

2. Parental delegation model

Except for the top-level startup class loader, all other class loaders have their own parent class loaders. The parent-child relationship is not implemented through inheritance, but through a combination relationship to reuse the parent class loader.

Working process: The class loader receives the class loading request –> delegates the request to the parent class loader (until the top-level class loader is started) –> the parent class attempts to load, and the loading failure is fed back to the child Class loader –> The subclass loader attempts to load the

Benefits of the parent delegation model: ensuring the stability of the Java underlying API and avoiding multiple differences caused by loading custom classes with the same name (Object) as the basic class Classes (Object) with the same name, causing confusion in the basic behavior of Java.

Parental delegation model source code:

The method adds a synchronization lock to ensure thread safety. First check whether the class has been loaded. If not, call the parent class loader. loadClass() method, if the parent class loader is empty, it means the startup class loader, then the startup class loader is called.

If the parent class fails to load, ClassNotFoundException will be thrown, and then call your own findClass() method to load it.

protected Class<?> loadClass(String name, boolean resolve)
    throws ClassNotFoundException
{
    //同步锁
    synchronized (getClassLoadingLock(name)) {
        // 首先检车这个类是不是已被加载
        Class<?> c = findLoadedClass(name);
        if (c == null) {
            long t0 = System.nanoTime();
            try {
                if (parent != null) {
                    //如果父类不为空则调用父类加载器的loadClass方法
                    c = parent.loadClass(name, false);
                } else {
                    //没有父类则默认调用启动类加载器加载
                    c = findBootstrapClassOrNull(name);
                }
            } catch (ClassNotFoundException e) {
                //如果父类加载器找不到这个类则抛出ClassNotFoundException
            }


            if (c == null) {
                // 父类加载器失败时调用自身的findClass方法加载
                long t1 = System.nanoTime();
                c = findClass(name);


                //记录
                sun.misc.PerfCounter.getParentDelegationTime().addTime(t1 - t0);
                sun.misc.PerfCounter.getFindClassTime().addElapsedTimeFrom(t1);
                sun.misc.PerfCounter.getFindClasses().increment();
            }
        }
        if (resolve) {
            resolveClass(c);
        }
        return c;
    }
}

3. Destruction of the Parental Delegation Model

1. The first destruction of the Parental Delegation Model

appeared in JDK1. After 2, while the class loader and abstract class java.lang.ClassLoader already existed.

Therefore, for forward compatibility, a new protected method findClass was added to ClassLoader after JDK1.2. Users write their own class loading logic in the findClass method instead of overriding the loadClass method to ensure that custom class loading complies with the parent delegation model.

2. The second destruction

The model itself is defective. Parental delegation can ensure the unification of the base classes of each class loader. This is when the user code calls the base class. It does not apply if the base class calls back to the user code. For example, in scenarios involving SPI, load the required SPI code.

For an introduction to the SPI mechanism, please refer to other articles.

In order to solve this problem, the thread context loader (Thread Context ClassLoader) is introduced. This class loader can be set through the setContextClassLoader() method in the java.lang.Thread class. If the thread is not created when The setting will be inherited from the parent thread. If there is none globally, the default is the application class loader. This loader can be used to complete the action of the parent class loader requesting the child class loader to load.

3. The third damage

is caused by the pursuit of program dynamics, such as hot deployment, hot replacement, etc.

For example, in the modular standard OSGi R4.2, the tree structure of parental delegation has been changed into a more complex network structure.
