Windows detects that the efi system partition is ntfs.

Windows detects that the efi system partition is ntfs

The reason for this problem: Your disk uses GPT partition, and you did not set uefi in the BIOS Startup or PE does not support uefi. (Recommended learning: PHP video tutorial)

Set uefi startup in BIOS

Operation preparation:

1. The motherboard supports UEFI;

2. The hard disk must be GPT in UEFI mode, otherwise the system cannot be installed.

Note: Regardless of whether it is uefi boot, Secure boot must be disabled, otherwise the boot disk cannot be recognized, and then the boot mode boot mode selects UEFI or Both to indicate that the uefi boot disk can be recognized

If you have these options in your BIOS, please set them as follows:

Secure Boot is set to Disabled [Disable startup security check, this is the most important]

OS Optimized is set to Others or Disabled [System type setting]

CSM (Compatibility Support Module) Support is set to Yes or Enabled

UEFI/Legacy Boot option is selected to Both

UEFI/Legacy Boot Priority is selected as UEFI First

How to turn on the motherboard UEFI mode

1. Press F2 to turn on the notebook and Del to enter the BIOS on the desktop. Different brands The method of booting the computer into the BIOS interface is also different;

2. Switch to Boot, select UEFI Boot and press Enter to set it to Enabled.

After completing the settings, you need to press F10 to save the changes.

For more PHP related technical articles, please visit the PHP Graphic Tutorial column to learn!

The above is the detailed content of Windows detects that the efi system partition is ntfs. For more information, please follow other related articles on the PHP Chinese website!
