Data visualization and chart display skills in Vue development

With the advent of the big data era, data visualization and chart display have become essential functions for more and more web applications. As a popular JavaScript framework, Vue also provides a wealth of tools and techniques to help developers achieve data visualization and chart display. In this article, we will introduce some commonly used data visualization and chart display techniques to help Vue developers build more visual and intuitive web applications.

1. Using Vue.js Echarts

Echarts is a JavaScript-based data visualization library that supports multiple chart types and data formats. Using Echarts in conjunction with the Vue.js framework allows us to build various data charts faster. When using Echarts, we can encapsulate Echarts components into Vue components and reuse them, thereby saving code and time.

In order to use Echarts, we need to install the two libraries echarts and vue-echarts:

npm i -S echarts vue-echarts

After the installation is complete, configure the following in Vue.js:

import Vue from 'vue'
import ECharts from 'vue-echarts'

// 引入ECharts各模块，并注册
import 'echarts/lib/chart/bar'
import 'echarts/lib/component/tooltip'

Vue.component('v-chart', ECharts)

Then We can reference and use it in the Vue component:

<template>
  <div>
    <v-chart :options="chartOption"></v-chart>
  </div>
</template>

<script>
export default {
  data () {
    return {
      chartOption: {
        xAxis: {
          type: 'category',
          data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']
        },
        yAxis: {
          type: 'value'
        },
        series: [{
          data: [820, 932, 901, 934, 1290, 1330, 1320],
          type: 'bar'
        }]
      }
    }
  }
}
</script>

2. Using Vue.js D3.js

D3.js is a tool for operating documents (Document ) JavaScript library that can create efficient and dynamic visual charts through data-driven DOM (Document Object Model). Used in conjunction with Vue.js, it can provide us with more flexible data display methods. D3.js is usually used to implement customized data visualization and charts, which requires developers to master certain SVG and CSS skills.

Install D3.js:

npm i -S d3

Introduce D3.js into Vue.js:

import * as d3 from 'd3'

Use D3.js in Vue components:

<template>
  <div>
    <svg></svg>
  </div>
</template>

<script>
export default {
  mounted () {
    // 画布大小
    const width = 400
    const height = 400

    // 在 body 里添加一个 SVG 画布
    const svg = d3.select('svg')
      .attr('width', width)
      .attr('height', height)

    // 定义一个数组
    const dataset = [250, 210, 170, 130, 90]

    // 定义比例尺
    const linear = d3.scaleLinear()
      .domain([0, d3.max(dataset)])
      .range([0, 300])

    // 定义坐标轴
    const axis = d3.axisBottom()
      .scale(linear)

    // 绘制矩形
    svg.selectAll('rect')
      .data(dataset)
      .enter()
      .append('rect')
      .attr('x', (d, i) => i * 70)
      .attr('y', d => height - linear(d))
      .attr('width', 65)
      .attr('height', d => linear(d))
      .attr('fill', 'steelblue')

    // 绘制坐标轴
    svg.append('g')
      .attr('transform', `translate(0, ${height})`)
      .call(axis)
  }
}
</script>

3. Using Vue.js Highcharts

Highcharts is a popular JavaScript charting library that provides various types of charts that are easy to use and customize. Combined with Vue.js, we can componentize Highcharts charts and quickly generate various charts.

Install Highcharts:

npm i -S highcharts highcharts-vue

Configure and use Highcharts in Vue.js:

import Vue from 'vue'
import HighchartsVue from 'highcharts-vue'
import Highcharts from 'highcharts'

Vue.use(HighchartsVue, {
  Highcharts
})

Then, reference and use it in the Vue component:

<template>
  <div>
    <highcharts :options="chartOptions"></highcharts>
  </div>
</template>

<script>
export default {
  data () {
    return {
      chartOptions: {
        chart: {
          type: 'line'
        },
        title: {
          text: 'Temperature Change'
        },
        xAxis: {
          categories: ['Jan', 'Feb', 'Mar', 'Apr', 'May', 'Jun', 'Jul', 'Aug', 'Sep', 'Oct', 'Nov', 'Dec']
        },
        yAxis: {
          title: {
            text: 'Temperature (°C)'
          }
        },
        series: [{
          data: [7.0, 6.9, 9.5, 14.5, 18.2, 21.5, 25.2, 26.5, 23.3, 18.3, 13.9, 9.6],
          color: '#ff9800'
        }]
      }
    }
  }
}
</script>

Conclusion

The above are some common methods of using data visualization and chart display skills in Vue.js development. Whether you use Echarts, D3.js or Highcharts, you can quickly build a variety of efficient and dynamic visual charts through the many functions provided by the Vue.js framework. In actual development, only by selecting appropriate charting tools and technologies can we provide users with a better data interaction and display experience.
