How to use PHP to implement a simple data chart display function

In the modern Internet era, the visual display of data is crucial for information transmission and decision-making analysis. Data charts are one of the common forms of data visualization, and PHP is a commonly used back-end development language with powerful data processing and chart generation capabilities. This article will introduce how to use PHP to implement a simple data chart display function and provide specific code examples.

Step 1: Prepare data
First, we need to prepare some data for display. Suppose we have a database of student test scores, containing the students' names and scores. We need to get data from the database and then perform corresponding processing and calculations.

// 假设数据库连接配置如下
$servername = "localhost";
$username = "root";
$password = "password";
$dbname = "test";

// 连接数据库
$conn = new mysqli($servername, $username, $password, $dbname);

// 检查连接是否成功
if ($conn->connect_error) {
    die("连接失败：" . $conn->connect_error);
}

// 查询数据
$sql = "SELECT name, score FROM students";
$result = $conn->query($sql);

// 将查询结果存储到一个数组中
$data = array();
if ($result->num_rows > 0) {
    while($row = $result->fetch_assoc()) {
        $data[] = $row;
    }
}

// 关闭数据库连接
$conn->close();

Step 2: Generate charts
After preparing the data, we need to use a suitable chart library to generate charts. Here, we will use Google Charts to generate a simple bar chart showing student performance.

// 构造用于生成图表的数据
$chart_data = "['学生', '分数'], ";
foreach ($data as $student) {
    $chart_data .= "['" . $student['name'] . "', " . $student['score'] . "], ";
}

// 去除最后一个逗号
$chart_data = rtrim($chart_data, ', ');

// 生成图表
echo
<<<HTML
<script type="text/javascript" src="https://www.gstatic.com/charts/loader.js"></script>
<script type="text/javascript">
// 加载Google Charts
google.charts.load('current', {'packages':['corechart']});
google.charts.setOnLoadCallback(drawChart);

function drawChart() {
    // 创建用于绘制图表的数据表
    var data = google.visualization.arrayToDataTable([
        $chart_data
    ]);

    // 设置图表选项
    var options = {
        title: '学生成绩',
        chartArea: {width: '50%'},
        hAxis: {
            title: '分数',
            minValue: 0
        },
        vAxis: {
            title: '学生'
        }
    };

    // 实例化图表对象并绘制图表
    var chart = new google.visualization.BarChart(document.getElementById('chart_div'));
    chart.draw(data, options);
}
</script>

<div id="chart_div" style="width: 800px; height: 400px;"></div>
HTML;

Step 3: Display the chart on the webpage
Finally, we need to display the generated chart on the webpage, so that users can view the chart by visiting the webpage.

Save the above code as a PHP file and access the file in the browser to see the generated chart.

Summary:
Through the above steps, we can use PHP to implement a simple data chart display function. First, we connect to the database and obtain the data that needs to be displayed; then, we use a suitable chart library to generate charts and set the corresponding chart options; finally, we display the generated charts on the web page for users to view. Through data processing and chart generation, we can understand the data more clearly and make relevant analyzes and decisions.

This is just a simple example. In actual use, you can choose different chart libraries and styles according to your needs, and further optimize and expand the functions. I hope this article can be helpful to readers who use PHP to implement data chart display functions.
