What is the command of cad circular array
- 尊渡假赌尊渡假赌尊渡假赌Original
- 2023-09-06 10:33:482401browse
The command for circular array in AutoCAD is "ARRAY". The following are the general steps for using the circular array command: 1. Enter "ARRAY" in the command line; 2. Select the object to be circularly arrayed; 3. Specify the array type and enter "Polar" or the abbreviated command "P"; 4. Specify the base point, which is the center point position of the annular array; 5. Specify the parameters of the annular array, such as radius, angle, etc.; 6. Select to complete the array or proceed Other settings are sufficient.
The operating system of this tutorial: Windows 10 system, AutoCAD 2024 version, Dell G3 computer.
In AutoCAD, the command for circular array is "ARRAY".
The following are the general steps for using the circular array command:
Enter the command: Enter "ARRAY" on the command line in AutoCAD.
Select objects: Follow the command prompts and select the objects to be circularly arrayed. You can select objects by clicking on them or using a selection command such as "PICK".
Specify the array type: At the command prompt, AutoCAD will ask you to specify the array type. Type "Polar" or the shorthand command "P" to indicate that you want to make a circular array.
Specify base point: AutoCAD will ask you to specify the base point, which is the center point position of the circular array. Specify the base point by clicking a point in the drawing area.
Specify circular parameters: According to the command prompt, AutoCAD will ask you to specify the parameters of the circular array, such as radius, angle, etc. Enter appropriate values as needed or click the relevant point in the drawing area.
Complete the array: According to the command prompt, you can choose to complete the array or make other settings. If you want to continue making changes to the array, you can choose to edit the array parameters.
Please note that the above steps are just general operation procedures. Specific command options and steps may vary between AutoCAD versions and configurations. It is recommended to consult AutoCAD's help documentation or search for related tutorials to get detailed command and operation instructions for the specific version you are using.
