Use C++ to implement various functions of embedded systems

Use C to realize various functions of embedded systems

With the widespread popularity of embedded system applications, people's requirements for embedded systems are getting higher and higher. . When designing embedded systems, we often need to consider issues such as system performance, stability, and scalability. As a powerful programming language, C can help us realize various functions of embedded systems. This article will introduce some common functions of embedded systems using C and provide corresponding code examples.

1. GPIO control
   In embedded systems, GPIO (General-purpose input/output) is a very commonly used function. Through GPIO, we can interact with external devices by controlling input and output ports. Below is a simple C code example that shows how to control GPIO using C.

#include <iostream>

#define GPIO_PIN 4

class GPIOControl {
public:
    void setMode(int pin, bool input) {
        // 设置GPIO引脚的输入/输出模式
        // ...
    }

    void setValue(int pin, bool value) {
        // 设置GPIO引脚的值
        // ...
    }
};

int main() {
    GPIOControl gpio;
    gpio.setMode(GPIO_PIN, false); // 设置GPIO引脚为输出模式
    gpio.setValue(GPIO_PIN, true); // 设置GPIO引脚输出高电平
    return 0;
}

2. Timer control
   Timer is one of the commonly used functions in embedded systems and can be used to implement timing, delay, interrupt and other functions. The following is a sample code using C to implement timer control.

#include <iostream>
#include <chrono>
#include <thread>

class TimerControl {
public:
    void startTimer(int interval) {
        // 设置定时器的时间间隔
        // ...

        std::chrono::milliseconds delay(interval);
        while (true) {
            // 定时器处理逻辑
            // ...

            std::this_thread::sleep_for(delay);
        }
    }
};

int main() {
    TimerControl timer;
    timer.startTimer(1000); // 设置定时器每隔1秒触发一次
    return 0;
}

3. Interrupt processing
   In embedded systems, interrupts are an important event processing mechanism. In C, we can use signal processing functions to handle interrupt events. Below is a sample code that uses C to handle the SIGINT signal (i.e. Ctrl C key press).

#include <iostream>
#include <csignal>

void signalHandler(int signal) {
    std::cout << "Received signal: " << signal << std::endl;
    // 中断信号处理逻辑
    // ...
}

int main() {
    std::signal(SIGINT, signalHandler); // 注册信号处理函数
    while (true) {
        // 嵌入式系统的主循环
        // ...
    }
    return 0;
}

4. Inter-process communication
   In embedded systems, inter-process communication (IPC) is a common requirement. C provides a variety of mechanisms to implement IPC, such as pipes, message queues, shared memory, etc. The following is a sample code using C to implement inter-process communication (pipeline).

#include <iostream>
#include <unistd.h>

int main() {
    int fd[2]; // 管道文件描述符
    char buffer[256];

    if (pipe(fd) == -1) {
        std::cerr << "Pipe creation failed" << std::endl;
        return 1;
    }

    pid_t pid = fork(); // 创建子进程
    if (pid == 0) {
        // 子进程写入数据到管道
        write(fd[1], "Hello, parent!", 14);
    } else {
        // 父进程从管道中读取数据
        read(fd[0], buffer, 256);
        std::cout << "Received message: " << buffer << std::endl;
    }
    return 0;
}

The above are just some simple examples of using C to realize the functions of embedded systems. The functions of embedded systems are relatively complex and diverse, and need to be expanded and modified according to specific needs during actual implementation. I hope this article will be helpful to readers when practicing embedded system development.
