CAD default line width is 0.25mm. How to check the default line width: 1. Open a CAD document and click "Tools" - "Options" on the top menu bar; 2. In the "Options" dialog box, switch to the "User Configuration Drawing" panel and click "Line "Width Setting"; 3. In the line width setting dialog box, you can see that the default value of line width is 0.25mm.

What is the default line width of cad

The operating environment of this tutorial: Windows 7 system, ZWCAD 2020 version, Dell G3 computer.

Line width is a basic attribute of graphic objects, but it does not belong to a geometric attribute. That is to say, changing the line width setting cannot change the appearance and shape of the graphic. After changing the line width, The thickness of the selected object will change. The main function of line width is to control printing, that is to say, to control the width of lines when printing graphics.

The default line width of cad is 0.25mm. If you want to change the default line width, you can change it on the cad line width setting page.

How to view the default line width

1. Open a CAD document and find the menu: [Tools]--[Options].

What is the default line width of cad

#2. Open the options menu, bring up the dialog box, and switch to the "User Configuration Diagram" panel. We can see the line width settings and click again.

What is the default line width of cad

3. Have you seen the line width setting dialog box? On the right side of the dialog box, there is a display line width. The default is 0.25mm

What is the default line width of cad

For more related knowledge, please visit the FAQ column!
