What does ac+ap networking mean?

AC AP is a networking solution for large homes or villas. It aims to maintain good network connections in every corner of the home. It is a WLAN system; AC AP networking is composed of AC Area coverage is achieved by commanding each AP, but the APs are not connected to each other, and the status of each AP can only be determined through the AC. The network system that makes up a complete AC AP mainly consists of four parts: router, AC controller, PoE switch and AP.

The operating environment of this tutorial: Windows 10 system, Dell G3 computer.

What are AC and AP

AP is the wireless access point and HUB in the traditional wired network. AP is equivalent to a bridge connecting wired network and wireless network. Its main function is to connect each wireless network client and then connect the wireless network to Ethernet, thereby achieving wireless network coverage.

AC is a wireless controller, a network device that performs centralized control of controlled wireless APs in a local area network. It is the core of the wireless network and is responsible for the management of all wireless APs in the wireless network. AP management includes: publishing configuration, modifying related configuration parameters, radio frequency intelligent management, access security control, etc.

What is AC AP networking?

AC AP is a networking solution for large apartments or villas. The purpose is to make the home It is a WLAN system that maintains good network connection in every corner.

AC AP networking is where the AC commands each AP to provide regional coverage, but the APs are not connected to each other. The status of each AP can only be determined through the AC. The connection is stable, but you can only Rely on AC for communication.

The network system that makes up a complete AC AP mainly consists of four parts: router, AC controller, PoE switch and AP.

• Router: It acts as a gateway between networks and is responsible for data exchange between the internal network and the external network.

• AC Controller: Manage and control the LAN. AP management includes: issuing configurations, modifying related configuration parameters, radio frequency intelligent management, and access security control. wait.

• PoE switch: In addition to providing the transmission function of an ordinary switch, a PoE switch can also provide power supply to the device at the other end of the network cable. This is mainly to provide DC power for the AP.

• #AP: Wireless access point, responsible for the wireless access function of mobile phones, computers, set-top boxes and some smart home appliances.

  According to function, AP can be divided into fat AP (FATAP) and thin AP (FITAP). Fat AP (FATAP) can also be said to be a wireless router, with AP and routing functions, and can be used alone. The thin AP (FITAP) only has the function of wireless access point. It needs to be used with AC and PoE switches.

AC AP networking advantages:

1. AC AP mode has a large capacity and supports seamless roaming , automatically switches AP, the switching time is very short, it can be said that the network will not be disconnected, and the roaming threshold can be set on the AC (this is a function that ordinary routers do not have).

2. AC AP mode management and setting is convenient. All wireless AP management is on the AC, and AP settings are also all on the AC. There is no need to configure each AP. One setting is uniformly distributed to all wireless APs, greatly reducing workload.

3. AC AP mode supports multiple SSIDs and can distinguish between internal and external use. You can also divide multiple internal SSIDs. Perform user access management.

4. The wireless AP in AC AP mode can be plugged in and used directly, no further settings are required, and it will be automatically recognized.

5. The AC AP mode also supports cloud management. No matter where you are and the network is available, you can check the working status of the device and manage the device in the cloud.

6. Some AC AP modes support authentication for Internet access, channel optimization, load balancing, etc.

AC AP networking disadvantages:

1. AC AP solution requires deploying network cables in advance and planning network cabling; later It is more uncomfortable to carry out remedial work.

2. The overall cost is higher, and the equipment cost is higher. Compared with Mesh, the AC controller cost, and the comprehensive wiring cost; panel AP usually has low power and small coverage, and requires a large number, so the cost is natural Also high.
