The range of class b IP addresses is "128.1.0.1~191.255.255.254". Class B IP address refers to the four-segment number of the IP address, the first two segments of which are network numbers. The length of the network identifier in the Class B IP address is 16 bits, and the length of the host identifier is 16 bits. Class B network addresses are suitable for medium-sized networks. There are 16,384 networks, and each network can accommodate more than 60,000 computers. tower.
The operating environment of this tutorial: Windows 7 system, Dell G3 computer.
IP address (Internet Protocol Address) refers to the Internet Protocol address, also translated as Internet Protocol address. The IP address is a unified address format provided by the IP protocol. It assigns a logical address to each network and each host on the Internet to shield the differences in physical addresses.
The Internet Committee has defined 5 IP address types to suit networks of different capacities, namely Class A ~ Class E. Among them, categories A, B, and C3 (table below) are uniformly allocated globally by InternetNIC, and categories D and E are special addresses. Let’s talk about Class B IP addresses.
Class B IP address
A Class B IP address means that among the four numbers in the IP address, the first two numbers are Network number. If the IP address is represented in binary, the Class B IP address consists of a 2-byte network address and a 2-byte host address. The highest bit of the network address must be "10". The length of the network identifier in the Class B IP address is 16 bits, and the length of the host identifier is 16 bits. Class B network addresses are suitable for medium-sized networks. There are 16,384 networks, and each network can accommodate more than 60,000 computers. tower.
Class B IP address range 128.0.0.1-191.255.255.254 (binary representation: 10000000 00000000 00000000 00000001----10111111 11111111 11111111 11111110). The last one is the broadcast address.
Private addresses and reserved addresses of Class B addresses
Default subnet mask
The default subnet mask for Class B addresses is 255.255.0.0, and the maximum number of hosts supported by each network It is 256 to the power of 2-2=65534 units. A Class B IP address consists of a 2-byte network address and a 2-byte host address. The highest bit of the network address must be "10", that is, the first number ranges from 128 to 191 . Each Class B address can connect to 65534 (2^16-2, because each host number cannot be 0,1) hosts at the same time. There are 16384 (2^14) Class B addresses on the Internet. For more related knowledge, please visit theFAQ column!
