What is the processor of Samsung s10?

Samsung s10 is equipped with Qualcomm Snapdragon 855 processor, using TSMC 7nm process, the CPU uses eight-core Kryo™ 485 architecture, the GPU uses Adreno™ 640, and the memory speed is 2133MHz; it supports GPS, GLONASS, and Beidou , Galileo, QZSS, SBAS and dual-frequency positioning.

#The operating environment of this tutorial: One UI 4 system, Samsung Galaxy S10 mobile phone.

Samsung S10 generally refers to Samsung Galaxy S10, which is a mobile phone product released by Samsung Electronics in San Francisco, USA on February 21, 2019; it was released in Wuzhen, China on February 28, 2019.

Samsung Galaxy S10 is equipped with a 6.1-inch full screen; is equipped with Qualcomm Snapdragon 855 processor and has a built-in 4100 mAh battery.

Appearance features

Samsung Galaxy S10 is equipped with a 6.1-inch Dynamic AMOLED curved screen with a hole punch It has a screen design and large rounded corners, and is equipped with three cameras horizontally on the back. The body uses nano-film technology to present a distinctive color effect; the body is 149.9mm long, 70.4mm wide, and 7.8mm thick; available in Haoyu White and Carbon Crystal Black There are four colors to choose from, glazed green and smoke blue.

Processor

Samsung Galaxy S10 is equipped with Qualcomm Snapdragon 855 processor, using TSMC 7nm Technology, the CPU uses the eight-core Kryo™ 485 architecture, which improves performance by about 45% compared to the Snapdragon 845 CPU. The GPU uses Adreno™ 640, which improves graphics rendering capabilities by about 20% compared with the previous generation product. It will be officially commercialized in the first quarter of 2019.

Snapdragon 855 is the world’s first commercial 5G mobile platform.

CPU

Processor Core

• 1 * Kryo™ 485 Gold ( 2.84GHz) 3 * Kryo™ 485 Gold (2.41GHz) 4 * Kryo™ 485 Silver (1.78GHz)

Number of Processors

• 64-bit

GPU

Processor Core

• Qualcomm Adreno™ 640 GPU

• 2*256 ALU (arithmetic logic unit)

Feature support

• Supports Vulkan 1.1, OpenGL ES 3.2, OpenCL 2.0 Full, Direct 3D 12.1

Memory

Memory speed: 2133MHz

Memory type: 4x16bit ,LPDDR4x

Display output

Maximum device display support: up to 4KHDR

Maximum external display support: up to two 4K HDR display devices

HDR support: HDR10, 10-bit bit depth, Rec 2020 color gamut

Wireless

Wi-Fi

• Wi-Fi standard: 802.11ad, 802.11ay, 802.11ax-ready, 802.11ac Wave 2, 802.11a/b/g, 802.11n

• Wi-Fi frequency band: 2.4 GHz, 5 GHz, 60 GHz

• Peak speed: 10 Gbps

• Qualcomm Wi-Fi 6-ready Technical features: 8x8 spatial streaming, 8x8 Detection, WPA3 security encryption support, target wake-up time, dual-band synchronization (DBS).

• Qualcomm 60 GHz Wi-Fi technical features: line-equivalent delay, always-on Wi-Fi sensing

Bluetooth

• Bluetooth version: 5.0

• Bluetooth speed: 2Mbps

Data function

• Module: Qualcomm Snapdragon ##Next generation calling service: VoLTE with SRVCC to 3G and 2G, HD and Ultra HD calling (EVS), CSFB to 3G and 2G

• Cellular network support: WCDMA (DB-DC -HSDPA, DC-HSUPA),TD-SCDMA,CDMA 1x,EV-DO,GSM/EDGE

• LTE support:LTE FDD,LTE TDD including CBRS support,LAA,LTE Broadcast

• LTE Type: Upload/Download LTE Type: LTE Category 20 Upload LTE Type: LTE Category 13 (Upload)

• LTE Speed ​​LTE Download Peak speed: 2 Gbps LTE Peak upload speed: 316 Mbps

• 5G5G Chip: Qualcomm Snapdragon Specifications: 800 MHz bandwidth, 8 carrier 2x2 MIMO (multivariable control system) 5G sub-6 GHz Specifications: 100 MHz bandwidth, 4x4 MIMO millimeter wave features: uplink and downlink dual-layer polarization, beam forming, beam steering, beam tracking

• DSP

• DSP: Qualcomm®Hexagon™690 processor, Qualcomm®Hexagon™ vector acceleration sensor, Qualcomm®Hexagon™ tensor acceleration sensor, Qualcomm®Hexagon™ voice assistant, Qualcomm All-Ways Aware™ technology.

Positioning

Supports GPS, GLONASS, Beidou, Galileo, QZSS, SBAS, dual-frequency positioning.

Screen

Equipped with a super-sensory full-view screen and passed HDR10 certification, it can achieve dynamic tone mapping in various scenes; in dark light environments, it can provide more satisfactory colors and contrast, and the screen can still perform well in bright sunlight. View image details more clearly. At the same time, the phone also has an eye-protecting display design that can adjust the brightness of blue light according to external light to achieve better visual effects. In order to obtain a better display effect during gaming and entertainment, the mobile phone is equipped with a fully upgraded Samsung AI Game Engine 2.0, which carries out system-level special optimization for various game scenarios.

Camera

Equipped with three rear cameras, including a telephoto camera, a wide-angle camera and a super camera that can take panoramic landscape shots Wide angle camera. Its intelligent variable aperture allows more light to enter, meeting the needs of scene exposure shooting in dark light. Samsung Galaxy S10 is also equipped with a front camera that condenses many advanced innovative technologies, including 4K UHD recording and dual cameras for artistic selfies that can focus in real time. It can also capture Hi-Motion videos without shaking in super stable mode. Even when switching between different scenes, the image is still relatively clear and smooth. The phone also has a series of functions such as frozen time shooting, intelligent scene optimization, real-time blurring, and dynamic cute shooting.

Under-screen fingerprint unlocking

Samsung Galaxy S10 uses an ultrasonic screen fingerprint unlocking solution. Compared with the optical screen fingerprint unlocking solution, it can detect water stains It can be unlocked normally, and there is no problem of recognition failure caused by light diffraction.
