How to reduce the size of a CAD file that is too large: First open the file operation interface and enter the PU character on the keyboard; then select "View items that can be cleaned" and find "Clean" or "All" in the current dialog box "Clean" and click to select; finally save.
The operating environment of this article: Windows 7 system, autocad2020 version, Dell G3 computer.
How to reduce the size of a cad file that is too large:
1. Find the CAD file that needs to be cleaned and click to open the CAD.
#2. After entering the CAD operation interface, enter the PU character on the keyboard. Then press Enter to confirm. As the title indicates.
#3. After confirmation, the following screen will pop up, and then select "View items that can be cleaned".
4. After selecting "View items that can be cleaned", then find "Clean" or "Clean All" in the current dialog box and click to select. As shown in the figure.
5. After clicking "Clean" or "Clean All", select "Clean All Items" or other options. As shown in the figure.
#6. After the cleaning is completed, the following schematic screen will appear in the operation bar at the bottom of the operation interface, and then click Close.
#7. After closing, resave the current drawing. The CAD file becomes smaller.
