How to connect mobile optical modem to wireless router

Fiber optic cat, also known as single-port optical transceiver, is a three-piece set of optical fiber transmission equipment developed for special user environments. Fiber optic cats usually have four output interfaces. Many times we need to connect multiple computers, including mobile phones for wireless WiFi. This time you need a wireless router. Let’s share how to connect a fiber optic cat to a wireless router.

Step 1. Connect the WAN port of the router to any LAN interface of the optical modem.

Step 2. Reset the router and press the Reset button on the router with a pin or other object.

Step 3. Open the browser, enter 192.168.1.1 in the address bar to open the router's management interface, enter the account number and password to log in; the router's default account password is: admin in lowercase.

What is the router setting URL? List of wireless router URLs of various brands-192.168.1.1

What is the router setting URL? 1. Check the router setting address through the label on the back of the router. Usually, the login address of each brand of router is usually marked on the label on the back of the router, which records the router’s management page address, password, serial number, etc...

Step 4. Click "Setup Wizard" on the left function menu>Select "Dynamic IP" and click Next;

##Steps 5. Set the SSID and wireless password and click Next;

Step 6. Click "Finish" and the router will automatically restart.

Step 7. After the restart is complete, log in to the router management again, click Network Parameters > LAN Port Settings > Enter the IP address: 172.168.1.1, and save. That is to change the original 192.168.1.1 to a new network segment, because the telecommunications optical modem uses this network segment, and the router cannot be the same as the optical modem.

The above is the specific operation of connecting the fiber optic modem to the wireless router. Please remind everyone that if the authentication account needs to be configured on the modem, you can plug your router into the modem's LAN port and set it to automatically obtain an address, or a static address can also be used. . If the authentication account needs to be authenticated on the router, it is usually set to PPPOE mode and just fill in the account password.
