Understanding the JVM memory layout and its role

The Java Virtual Machine (JVM) is the core component of the Java language, and its goal is to execute Java bytecode. JVM memory layout refers to the memory distribution used by the JVM during runtime, including thread private areas and thread shared areas. Understanding JVM memory layout is very important for developers as this helps us better optimize and debug our Java applications. This article will introduce the memory layout of the JVM and its role, and provide some specific code examples.

The JVM memory layout is mainly divided into thread private areas and thread shared areas. The thread private area includes the program counter, Java virtual machine stack and local method stack. The thread shared area includes the method area and heap.

1. Program Counter Register
   The program counter is a small memory space that is used to indicate the location of the bytecode instructions executed by the current thread. In a multi-threaded environment, each thread will have a dedicated program counter. The function of the program counter is to record the execution position of the thread. When the thread is interrupted, the JVM can resume to the position pointed by the program counter.
2. Java Virtual Machine Stacks
   The Java virtual machine stack is private to the thread, and its life cycle is the same as the thread. Each thread will have a corresponding virtual machine stack used to store local variables, operand stacks and return values ​​of methods. When a thread calls a method, the JVM creates a stack frame for the method and stores it in the virtual machine stack. The stack frame includes information such as method parameters, local variables, and the address returned after execution.
3. Native Method Stacks
   The local method stack is similar to the virtual machine stack. The difference is that the local method stack serves Native methods (that is, methods written in languages ​​​​such as C and C). The function of the native method stack is to support the calling of Native methods.
4. Method Area (Method Area)
   The method area is shared by threads. It is used to store metadata of the class (such as class name, field information, method information, etc.) and constant pool (store String, Number and other constants). When the JVM starts, the system will load the bytecode file into the method area. In the method area, there is also a special area - the runtime constant pool, which is part of the method area and is used to store symbol references generated after compiling the bytecode file.
5. Heap
   The heap is also shared by threads and is used to store object instances and arrays. When we use the new keyword to create an object, the JVM will allocate a memory space on the heap to store the object's data. The heap is the focus area of ​​the garbage collector, which regularly cleans and recycles useless objects.

Let’s look at some specific code examples to further understand the memory layout of the JVM.

1. Program Counter Example:

   public class ProgramCounterExample {
    public static void main(String[] args) {
        int x = 10;
        int y = 20;
        int sum = x + y;
        System.out.println(sum);
    }
   }

   In this example, we use the program counter to record the execution position of the current thread.

2. Virtual machine stack example:

   public class StackExample {
    public static void main(String[] args) {
        int result = calculateSum(10, 20); // 调用calculateSum方法
        System.out.println(result);
    }

    public static int calculateSum(int x, int y) {
        int sum = x + y; // 在虚拟机栈中创建栈帧
        return sum;
    }
   }

   In this example, we use the virtual machine stack to store the local variables of the method and the address returned after execution.

3. Method area example:

   public class MethodAreaExample {
    public static void main(String[] args) {
        String message = "Hello, world!"; // 在方法区的常量池中存放字符串常量
        System.out.println(message);
    }
   }

   In this example, we use the constant pool in the method area to store string constants.

Summary:
Understanding the memory layout of the JVM and its role is very important for developers. The program counter, virtual machine stack, local method stack, method area and heap are the five main parts that constitute the JVM memory layout. By understanding the JVM memory layout, we can better optimize and debug Java applications and improve program performance and stability.
