How to remove the CPU fan frame

php editor Baicao is here to introduce to you how to disassemble the CPU fan frame. When we need to clean or replace the CPU fan, removing the fan frame is an essential step. First, make sure the computer is turned off and unplugged from the power source. Then, depending on the specific computer model, find the fixing screws or buckles of the CPU fan frame. Typically, a screwdriver or other appropriate tool is required to loosen or snap the screws open. Be careful when disassembling to avoid damaging other parts. After disassembly is complete, you can clean or replace the CPU fan. Remember to reverse the steps when reinstalling to make sure the fan frame is securely installed.

#How to remove the cpu fan frame?

1 First, you need to remove the CPU fan from the computer motherboard. 2 To remove the fan frame, you need to first find the screws or buckles that fix the frame, and remove these fixings one by one. 3. You can use professional tools or manually to separate the frame and the fan. Be careful not to damage the connection between the frame and the fan. Disassembly of computer parts requires caution. It is recommended to obtain relevant knowledge or seek professional help to avoid irreparable losses. At the same time, when replacing the fan, you can consider purchasing high-quality, low-noise products to improve the performance and user experience of the computer.

How to remove the fan blades from a computer power supply cooling fan?

How to disassemble the CPU fan.

Different CPU fans have different removal methods.

There are two common ways to fix the CPU fan,

1) One is to fix it with screws and a backing plate. This kind can be taken out by unscrewing the screws directly with a screwdriver.

2) One is to buckle it on directly, just like how to buckle the tag on ordinary clothes. First remove the motherboard screws, and then directly remove the CPU fan.

In general, to remove the computer CPU fan, first remove the fan and the base connecting the fan. The fan is connected to the base with screws, and the base is connected to the motherboard with clips; the fan and the base After disassembly, you will find the CPU. There is a pressure lever next to it. Check the direction, lift the pressure lever, and take the CPU out vertically. The entire CPU fan has been disassembled.

How to remove the motherboard radiator?

1. Find the buckles at the four corners of the radiator and rotate the knob 90 degrees counterclockwise. Then take the host apart and measure the original fan condition for better comparison later. The previous fan noise was stable at around 37.

2. Just lift up the buckle. It is necessary to remove all the original radiator motherboard. Use a wowstick electric screwdriver when disassembling. After all four buckles are lifted, you can lift up the radiator to remove it. After the final disassembly, Just clean the remaining silicone on the processor.

3. The most common computer problems are automatic restart and crash, which are usually caused by overheating of the CPU processor. Sometimes the CPU cooling silicone grease has dried or there is too much dust. If it is not removed, It is difficult to clean the dust inside the CPU radiator. Thick dust makes it difficult for the heat on the radiator to dissipate. The CPU radiator is used to dissipate heat for the CPU. The radiator plays a decisive role in the stable operation of the CPU.

How to remove the fan from the motherboard?

1. First, use a flat-blade screwdriver or your hand to loosen the tightening bolts at the four corners of the CPU fan.

2. Then pull up the tightening bolts at the four corners of the fan.

3. Then unplug the power cord between the fan and the motherboard.

4. At this time, you can remove the fan directly by hand.

5. Take a look at the principle of the fan fixing pin. It is composed of two pieces of plastic as a tightening pin, with a tightening pin inserted in the middle.

How to remove the fan on the computer motherboard? ?

1. First, use a flat-blade screwdriver or your hand to loosen the tightening bolts at the four corners of the CPU fan.

2. Then pull up the tightening bolts at the four corners of the fan.

3. Then unplug the power cord between the fan and the motherboard.

4. At this time, you can remove the fan directly by hand.

5. Take a look at the principle of the fan fixing bolt foot. It is composed of two pieces of plastic as a tightening bolt, with a tightening bolt inserted in the middle.

6. When the tightening bolt is inserted into the motherboard fan fixing hole, insert the tightening bolt between the two tightening bolts.

7. In this way, the fan can be fixed and pressed on the CPU, so you only need to operate in the opposite direction when disassembling.

How to remove and install the CPU fan?

.Use a flat-blade screwdriver or your hand to loosen the tightening bolts at the four corners of the CPU fan.

2. Pull up the tightening bolts at the four corners of the fan.

3. Unplug the power cord between the fan and the motherboard.

4. At this time, you can remove the fan directly by hand.

5. Let’s take a look at the principle of the fan fixing bolt foot. It is composed of two pieces of plastic as a tightening bolt, with a tightening bolt inserted in the middle.

6. When the tightening bolt is inserted into the motherboard fan fixing hole, insert the tightening bolt between the two tightening bolts, so that the fan can be fixed and pressed on the CPU. Therefore, you only need to reverse it when disassembling. Just operate the direction.

How to disassemble the computer fan blade?

1. There is a button on both sides of the fan. If you press it and it doesn't come loose, use a flat-blade screwdriver to undo the four buttons of the bracket.

2. Then unplug the cable connecting the computer fan and the computer motherboard.

3. Next, pick up the fan directly and be gentle so as not to damage the motherboard.

4. Finally, take a closer look at the fixing bolt of the computer fan. It is clamped by two plastic openings, and a tensioning bolt is added between them. Insert the tension bolt into the fan fixing hole on the motherboard, and then insert the tension bolt into the center of the two tension bolts. This way the fan can be fixed and pressed on the CPU, so you only need to operate in the opposite direction when disassembling.

How to remove the downward pressure CPU fan?

Step 1: Arrange the fan

When organizing the fan, you must pay attention to the position of the fan power cord and buckle button. The cords must be sorted out in advance to avoid any misalignment of the fan during operation. The initial position of the power cord is usually inside the fan (it can be taken out).

Step 2: Adjust the position of the radiator

Adjust the radiator to the appropriate position, place the fan horizontally above the processor cover, and tighten the buckle posts (tips) around the buckle The bottom of the antenna) needs to be aligned with the four buckle points on the motherboard.

3 The motherboard button holes of Intel processors are located near the CPU socket, and users can easily find them by looking at the motherboard. Before installing the original Intel radiator, be sure to check whether the rotary switch is completely restored to its original position (original position: where the dot is next to the radiator).

Step 4: Press the buckles

Since the radiator buckle is designed with four buckles, the best way to install the buckles is the "diagonal" pressing installation method. Sequential pressing can easily cause uneven force on the fan, making it difficult to press the other two buckles.

Note that you need to apply more force when pressing the button of the buckle. When you hear a crisp click sound, it proves that the pressing is successful.

After installing the radiator, we need to connect the power cable of the radiator fan (4Pin interface of the fan) to the heat dissipation power supply interface of the motherboard.

Step 5: Remove the fan

To remove the radiator, you first need to remove the power cord, separate the fan power cord from the motherboard, and then disassemble the radiator buckle.

How to remove the cooling fan?

1. First unplug the power cord of the cooling fan from the motherboard.

2. Then remove the screws fixing the fan (heat sink) from the motherboard.

3. Generally, the fan and heat sink can be removed in this way. The problem is that some screws that fix the fan (heat sink) have a "card" under the heat sink, which connects the heat sink and the fan together and cannot be separated. Just take off the "card" slowly, or if it doesn't work, just cut it off.

How to remove the FANUC drive cooling fan?

When disassembling the Fanuc drive cooling fan, be sure to disconnect the power supply and follow these steps:

1. Open the case: Depending on your specific device model, open the Fanuc drive chassis. A screwdriver or other appropriate tool is usually required to remove the case cover.

2. Locate the fan: In the open case, locate the cooling fan mounted above or on the side of the drive. The fan is usually attached to the drive or case with screws or buckles.

3. Disconnect the power supply: Before removing the fan, find the power cord connected to the fan. Typically, the fan's power cord is pluggable, and you can disconnect the power by simply unplugging the power connector.

4. Remove the fan: Use the corresponding tools to remove the fan from the drive or chassis according to the fixing method (screws or buckles). If there are screws, use an appropriately sized screwdriver to loosen them by turning them. If using a buckle, locate the buckle and press or release the buckle to unsecure it.

5. Clean or replace the fan: Once the fan is removed, you can clean its surface or use compressed air to blow away the dust. If the fan needs to be replaced, be sure to purchase a new one that is compatible with the device.

6. Install the fan: Secure the cleaned fan or new fan back to the drive or case. Reverse the previous steps to reconnect the power cord and secure the fan properly.

7. Close the chassis: After ensuring that all connections are normal, reinstall the chassis cover and secure it to the chassis with a screwdriver or appropriate tool.
