Analysis of CSS relative positioning properties: relative and z-index

CSS relative positioning attribute analysis: relative and z-index, specific code examples are required

Introduction:
In web design, we sometimes need to adjust the elements location and display level. CSS relative positioning properties can help us achieve these effects. This article will analyze the relative property and z-index property in CSS relative positioning properties in detail and provide specific code examples.

1. The role and usage of the relative attribute
The relative attribute in CSS can help us fine-tune the original position of the element. Relative positioning does not break away from the standard document flow, and the actual position of the element remains unchanged. The following is the common syntax of the relative attribute:

.element {
  position: relative;
  top: 20px;
  left: 10px;
}

In the above code, .element is the element that needs to be set to relative positioning, top and left The attributes respectively represent the downward and right offsets of the element relative to its original position.

A common example of using the relative attribute is to add a text description to an image and place the description directly below the image. The code example is as follows:

<div class="image-container">
  <img src="/static/imghwm/default1.png"  data-src="image.jpg"  class="lazy" alt="图片">
  <div class="caption">这是一张图片的描述</div>
</div>

.image-container {
  position: relative;
  width: 200px;
  height: 200px;
}
.caption {
  position: relative;
  top: 100%;
  text-align: center;
}

In the above code, we set the relative positioning through .image-container and the top of the element through .caption: 100% Place the text description directly below the image.

2. The role and usage of the z-index attribute
The z-index attribute in CSS is used to set the hierarchical order of elements. Elements with larger z-index values ​​will overwrite elements with smaller z-index values. The following is the common syntax of the z-index attribute:

.element {
  position: relative;
  z-index: 2;
}

In the above code, .element is the element that needs to set the hierarchical order, and the z-index attribute is used to Specify a numeric value indicating the hierarchical order of elements.

Use the z-index attribute to achieve the cascading effect of elements. For example, we can create a simple layer overlay effect. The code example is as follows:

<div class="box red"></div>
<div class="box green"></div>
<div class="box blue"></div>

.box {
  position: relative;
  width: 100px;
  height: 100px;
  margin-bottom: 20px;
}

.red {
  background-color: red;
  z-index: 1;
}

.green {
  background-color: green;
  z-index: 2;
}

.blue {
  background-color: blue;
  z-index: 3;
}

In the above code, we create three squares with different background colors and set different settings for each square. z-index value. Since .blue has the largest z-index value, it will appear at the top, .green in the middle, and .red at the bottom.

Summary:
The relative value of the CSS relative positioning attribute and the z-index value of the hierarchical order attribute play an important role in web design. With the relative property, we can fine-tune the position of an element. Through the z-index attribute, we can control the stacking order of elements. Learn to use these two attributes flexibly to make web pages richer and more diverse.

The above is the analysis of CSS relative positioning properties relative and z-index. I hope it will be helpful to readers. In actual development, these attributes can be flexibly used according to specific needs to achieve more exciting web design effects.
