With the rapid development of the Internet, cross-language remote procedure calls (RPC) play a role in distributed systems plays an important role. In the traditional RPC architecture, HTTP or TCP protocols are usually used for communication, but this method still needs to be improved in terms of performance and concurrency capabilities.

In order to solve this problem, this article will introduce how to use ThinkPHP6 and Swoole to develop a high-performance RPC service. First, we will briefly introduce ThinkPHP6 and Swoole, and then explain in detail how to build and use this RPC service.

1. Overview of ThinkPHP6

ThinkPHP is a free and open source, fast, simple and elegant PHP development framework. It follows the MVC design pattern and has rich features, such as routing, middleware, model association, etc. Its version 6 is refactored and optimized based on ThinkPHP5, providing more powerful and efficient functions.

2. Overview of Swoole

Swoole is an asynchronous, high-performance network communication framework written in C language. It can extend the functions of PHP, provide better concurrent processing capabilities, and greatly improve the performance of the system. It supports multiple protocols such as coroutines, TCP/UDP/HTTP/WebSocket, and provides a rich API for developers to use.

3. Build RPC service

1. Install ThinkPHP6

First, we need to install ThinkPHP6 through Composer.

composer create-project topthink/think=6.* project_name

2. Install Swoole

Next, we need to install the Swoole extension through Pecl.

pecl install swoole

After the installation is completed, you need to add the following content to the php.ini file:

extension=swoole

3. Create an RPC server

Create an RpcServer class in the project and inherit it Since the SwooleServer class, and override the onReceive method.

namespace appserver;

use SwooleServer;

class RpcServer extends Server
{
    public function onReceive($server, $fd, $reactor_id, $data)
    {
        // 解析请求数据
        $request = unserialize($data);

        // 调用对应的方法
        $result = $this->callMethod($request['class'], $request['method'], $request['params']);

        // 发送响应数据
        $server->send($fd, serialize($result));

        // 关闭连接
        $server->close($fd);
    }

    private function callMethod($class, $method, $params)
    {
        // 实例化类
        $obj = new $class();

        // 调用方法
        return call_user_func_array([$obj, $method], $params);
    }
}

4. Create RPC client

Create an RpcClient class in the project to send requests to the RPC server.

namespace appclient;

use SwooleClient;

class RpcClient
{
    public static function call($serverIp, $serverPort, $class, $method, $params)
    {
        $client = new Client(SWOOLE_SOCK_TCP);
        if (!$client->connect($serverIp, $serverPort)) {
            throw new Exception("Failed to connect to server");
        }

        // 构建请求数据
        $request = serialize([
            'class' => $class,
            'method' => $method,
            'params' => $params,
        ]);

        // 发送请求数据
        $client->send($request);

        // 接收响应数据
        $result = unserialize($client->recv());

        // 关闭连接
        $client->close();

        return $result;
    }
}

5. Call the RPC service

Create a TestController class in the project to call the RPC service.

namespace appcontroller;

use appclientRpcClient;

class TestController
{
    public function index()
    {
        // 调用RPC服务
        $result = RpcClient::call('127.0.0.1', 9501, 'appserviceTestService', 'hello', ['ThinkPHP']);

        echo $result;
    }
}

4. Summary

This article introduces how to use ThinkPHP6 and Swoole to develop a high-performance RPC service. First, we give a brief overview of ThinkPHP6 and Swoole, and then explain in detail how to build and use this RPC service. I hope this article will help you understand and implement high-performance RPC services.
