How to do image recognition and processing in C++?

How to perform image recognition and processing in C?

Image recognition and processing is one of the important research directions and application areas in the field of computer vision. In the C programming language, we can easily realize image recognition and processing by calling relevant libraries and functions. This article will introduce the basic methods of image recognition and processing in C and provide code examples as a reference.

1. Image reading and display
Before image recognition and processing, the image needs to be read and displayed first. The OpenCV library can be used in C to implement this functionality. The following is a code example for reading and displaying images:

#include <opencv2/opencv.hpp>
using namespace cv;

int main()
{
    Mat image = imread("image.jpg");  // 读取图像
    if (image.empty())
    {
        printf("无法打开图像
");
        return -1;
    }

    namedWindow("图像", WINDOW_NORMAL);  // 创建窗口
    imshow("图像", image);  // 显示图像
    waitKey(0);  // 等待按键
    return 0;
}

2. Image recognition
Image recognition is to determine the object or scene represented by the image based on the content of the image. Common image recognition tasks include face recognition, target detection, etc. In C, we can use machine learning libraries and algorithms for image recognition. The following takes face recognition as an example to introduce how to implement image recognition in C:

#include <opencv2/opencv.hpp>
#include <opencv2/face.hpp>
using namespace cv;
using namespace cv::face;

int main()
{
    CascadeClassifier cascade;
    cascade.load("haarcascade_frontalface_default.xml");  // 加载人脸分类器

    Mat image = imread("image.jpg");  // 读取图像
    if (image.empty())
    {
        printf("无法打开图像
");
        return -1;
    }

    std::vector<Rect> faces;
    cascade.detectMultiScale(image, faces);  // 人脸检测

    for (int i = 0; i < faces.size(); i++)
    {
        rectangle(image, faces[i], Scalar(255, 255, 0), 2);  // 人脸框出
    }

    namedWindow("人脸识别", WINDOW_NORMAL);  // 创建窗口
    imshow("人脸识别", image);  // 显示图像
    waitKey(0);  // 等待按键
    return 0;
}

Among them, we use the cascade classifier (CascadeClassifier) ​​in OpenCV to implement face recognition. This classifier is a machine learning algorithm based on Haar features that can detect face areas in images.

3. Image processing
Image processing involves various operations on images, such as filtering, edge detection, image enhancement, etc. In C, we can use various image processing functions provided by OpenCV to implement these operations. The following takes image grayscale and edge detection as an example to introduce how to perform image processing in C:

#include <opencv2/opencv.hpp>
using namespace cv;

int main()
{
    Mat image = imread("image.jpg");  // 读取图像
    if (image.empty())
    {
        printf("无法打开图像
");
        return -1;
    }

    Mat grayImage;
    cvtColor(image, grayImage, COLOR_BGR2GRAY);  // 图像灰度化

    Mat edgeImage;
    Canny(grayImage, edgeImage, 50, 150);  // 边缘检测

    namedWindow("灰度图像", WINDOW_NORMAL);  // 创建窗口
    imshow("灰度图像", grayImage);  // 显示灰度图像

    namedWindow("边缘图像", WINDOW_NORMAL);  // 创建窗口
    imshow("边缘图像", edgeImage);  // 显示边缘图像

    waitKey(0);  // 等待按键
    return 0;
}

In the above code, we use the cvtColor function in OpenCV to convert the color image into a grayscale image. Use Canny function for edge detection.

To sum up, this article introduces the basic methods of image recognition and processing in C and provides relevant code examples. Readers can conduct further research and development according to their own needs and actual conditions. Through C's image recognition and processing technology, we can carry out more meaningful work in the field of computer vision.
