How to implement car track animation with css

How to implement rail animation with css: 1. Create an HTML file and define the div as "

"; 2. Set the CSS classes to mountains and train; 3. Realize the track animation by using the animation properties of CSS3 and the animation frame "@keyframes".

How to implement car track animation in css?

Pure CSS3 cartoon train animation

#Since Since CSS3 became popular, animations based on pure CSS3 have emerged in endlessly, including pure CSS3 character animation, pure CSS3 button animation, etc. This time, we share with you a very good CSS3 cartoon train animation running along the track. A cartoon-style train passes slowly, especially the animation design of the locomotive, which is very cute and realistic.

---

By the way, I found that when I post HTML and other articles, you like them and add them to your favorites. When I post C, Java and the like, no one reads them. What do you mean?

---

Effect preview

##Code implementation

HTML code

<div class="center">
  <div class="mountains"></div>
  <div class="train">
    <div class="engine-front">
      <div class="chimney">
        <div class="smoke"></div>
        <div class="smoke smoke-2"></div>
        <div class="smoke smoke-3"></div>
        <div class="smoke smoke-4"></div>
      </div>
    </div>

    <div class="engine-body"></div>

    <div class="compartment">
      <div class="compartment-window"></div>
    </div>

    <div class="compartment compartment-two">
      <div class="compartment-window"></div>
    </div>

    <div class="compartment compartment-three">
      <div class="compartment-window"></div>
    </div>

    <div class="wheel-holder">
      <div class="wheel"></div>
      <div class="wheel wheel-2">
        <div class="wheel-joint"></div>
        <div class="wheel-joint wheel-joint-2"></div>
      </div>
      <div class="wheel wheel-3"></div>
      <div class="wheel wheel-4"></div>
      <div class="wheel wheel-5"></div>
      <div class="wheel wheel-6"></div>
      <div class="wheel wheel-7"></div>
      <div class="wheel wheel-8"></div>
      <div class="wheel wheel-9"></div>
    </div>
  </div>
  <div class="bridge"></div></div>

The structure of the HTML code is very clear. Generally speaking, it is divided into two parts. One part is the bright moon, mountains and starry sky as the background, and the corresponding CSS class is

mountains

; the other is One part is a moving train, and the corresponding CSS class is train. The train part is relatively complicated, with elements such as a locomotive, engine, track, wheels, carriages, etc., which will be explained one by one in the following CSS code.

CSS codeThe background part draws two mountains, a bright moon and a clear starry sky.

.mountains {
  height: 100%;
  position: absolute;
  width: 100%;
  z-index: 1;}.mountains::before, .mountains::after {
  background: #000c18;
  background: -moz-linear-gradient(#012a53, #000c18 50%);
  background: -webkit-linear-gradient(#012a53, #000c18 50%);
  background: -o-linear-gradient(#012a53, #000c18 50%);
  background: -ms-linear-gradient(#012a53, #000c18 50%);
  background: linear-gradient(#012a53, #000c18 50%);
  content: "";
  height: 100%;
  position: absolute;}.mountains::before {
  border-radius: 100% 300% 0 0;
  left: -20%;
  width: 57%;}.mountains::after {
  border-radius: 300% 100% 0 0;
  right: -20%;
  width: 80%;}

Then there is the bridge part of the train track, which is also very simple

.bridge {
  border-bottom: 0.3rem solid white;
  border-top: 0.3rem solid white;
  background: black;
  background: -webkit-linear-gradient(55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem, -webkit-linear-gradient(-55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem;
  background: -moz-linear-gradient(55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem, -moz-linear-gradient(-55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem;
  background: -o-linear-gradient(55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem, -o-linear-gradient(-55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem;
  background: -ms-linear-gradient(55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem, -ms-linear-gradient(-55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem;
  background: linear-gradient(55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem, linear-gradient(-55deg, transparent 46%, white 46%, white 54%, transparent 54%) left/1.6rem 2.2rem;
  bottom: 10rem;
  height: 2.6rem;
  position: absolute;
  width: 100%;
  z-index: 1;}

After that is the main part of this animation, the train. Each part has a corresponding CSS class to describe it. Please Look at the code:

.train {
  animation: move-train 24s linear infinite;
  bottom: 12.6rem;
  height: 10rem;
  position: absolute;
  left: calc(100% + 1.3rem);
  width: 44rem;
  z-index: 1;}.engine-front, .engine-front::before, .engine-front::after {
  background: #0f0f0f;
  background: linear-gradient(0deg, #0f0f0f, #262626, #0f0f0f);
  border: 0.1rem solid rgba(255, 255, 255, 0.15);
  border-radius: 50% 0 0 50%;
  border-right: none;}.engine-front {
  animation: body-upDown 0.3s infinite;
  border-radius: 0.5rem 0 0 0.5rem;
  bottom: 1.4rem;
  height: 4.6rem;
  left: 0;
  position: absolute;
  width: 8rem;}.engine-front::before, .engine-front::after {
  content: "";
  position: absolute;
  height: 70%;
  left: -0.9rem;
  top: 50%;
  transform: translate(0, -50%);
  width: 0.8rem;}.engine-front::after {
  height: 40%;
  left: -1.4rem;
  width: 0.5rem;}.chimney {
  background: #990000;
  height: 2.2rem;
  left: 2.5rem;
  position: absolute;
  top: -2.3rem;
  width: 1.7rem;}.chimney::before, .chimney::after {
  content: "";
  position: absolute;}.chimney::before {
  animation: up-down 0.3s infinite;
  border-bottom: none;
  border-left: 0.5rem solid transparent;
  border-right: 0.5rem solid transparent;
  border-top: 0.8rem solid orange;
  left: 50%;
  top: -0.9rem;
  transform: translate(-50%, 0);
  width: 160%;}.smoke {
  animation: move-smoke 0.4s linear infinite;
  background: rgba(255, 255, 255, 0.8);
  border-radius: 50%;
  height: 1.4rem;
  left: 0.2rem;
  position: absolute;
  top: -1.5rem;
  width: 0.8rem;
  z-index: -1;}.smoke-2 {
  animation-delay: 0.1s;
  left: 0.4rem;}.smoke-3 {
  animation-delay: 0.2s;
  left: 0.6rem;}.smoke-4 {
  left: 0.8rem;}.engine-body {
  animation: body-upDown 0.3s 0.1s infinite;
  background: #b30000;
  background: linear-gradient(0deg, #330000, red, #990000);
  border-radius: 0 0 0.4rem 0;
  bottom: 1.4rem;
  height: 7rem;
  left: 8rem;
  position: absolute;
  width: 5rem;}.engine-body::before, .engine-body::after {
  content: "";
  left: 50%;
  position: absolute;
  transform: translate(-50%, 0);}.engine-body::before {
  animation: up-down 0.3s 0.2s infinite;
  background: #660000;
  background: linear-gradient(0deg, #660000, #990000, #660000);
  border-radius: 50% 50% 0 0;
  height: 1.2rem;
  top: -1.2rem;
  width: 130%;}.engine-body::after {
  background: #b3e0f2;
  border-radius: 0.2rem;
  height: 40%;
  top: 1rem;
  width: 45%;}.wheel::before, .wheel::after {
  left: 50%;
  top: 50%;
  transform: translate(-50%, -50%);}.wheel-holder {
  height: 2.8rem;
  bottom: 0;
  position: absolute;
  width: 100%;}.wheel {
  animation: rotate 2s linear infinite;
  background: orange;
  border: 0.3rem solid rgba(0, 0, 0, 0.6);
  border-radius: 50%;
  height: 2.8rem;
  left: 1rem;
  position: absolute;
  width: 2.8rem;}.wheel-2 {
  left: 4.5rem;}.wheel-3 {
  border-width: 0.5rem;
  height: 3.8rem;
  left: 8.7rem;
  top: -1.1rem;
  width: 3.8rem;}.wheel-4 {
  left: 15.7rem;}.wheel-5 {
  left: 19.5rem;}.wheel-6 {
  left: 25.7rem;}.wheel-7 {
  left: 29.5rem;}.wheel-8 {
  left: 35.7rem;}.wheel-9 {
  left: 39.5rem;}.wheel::before, .wheel::after {
  content: "";
  position: absolute;}.wheel::before {
  background: rgba(0, 0, 0, 0.3);
  height: 86%;
  width: 0.2rem;}.wheel::after {
  background: #996300;
  background: -webkit-radial-gradient(circle at center, #b37400 30%, #996300 30%);
  background: -moz-radial-gradient(circle at center, #b37400 30%, #996300 30%);
  background: -o-radial-gradient(circle at center, #b37400 30%, #996300 30%);
  background: -ms-radial-gradient(circle at center, #b37400 30%, #996300 30%);
  background: radial-gradient(circle at center, #b37400 30%, #996300 30%);
  border-radius: 50%;
  height: 40%;
  width: 40%;}.compartment {
  animation: body-upDown 0.3s infinite;
  background: #186c8e;
  background: -webkit-linear-gradient(#104b63 50%, #1f8dba);
  background: -moz-linear-gradient(#104b63 50%, #1f8dba);
  background: -o-linear-gradient(#104b63 50%, #1f8dba);
  background: -ms-linear-gradient(#104b63 50%, #1f8dba);
  background: linear-gradient(#104b63 50%, #1f8dba);
  border-radius: 0 0 0.3rem 0.3rem;
  bottom: 1.4rem;
  height: 5rem;
  left: 15rem;
  position: absolute;
  width: 8rem;}.compartment-two {
  animation: body-upDown 0.3s 0.1s infinite;
  left: 25rem;}.compartment-two .compartment-window::before {
  animation: up-down 0.3s 0.3s infinite;}.compartment-three {
  animation: body-upDown 0.3s 0.2s infinite;
  left: 35rem;}.compartment-three .compartment-window::before {
  animation: up-down 0.35s infinite;}.compartment::before, .compartment::after {
  background: black;
  border: 0.4rem solid transparent;
  bottom: 0.4rem;
  box-shadow: 0 0 0 1px rgba(255, 255, 255, 0.1);
  content: "";
  height: 0.8rem;
  position: absolute;
  width: 0.9rem;}.compartment::before {
  border-left: 0.4rem solid rgba(255, 255, 255, 0.3);
  left: -0.9rem;}.compartment::after {
  border-right: 0.4rem solid rgba(255, 255, 255, 0.3);
  left: -2rem;}.compartment-window {
  background: #1f8dba;
  background: -moz-linear-gradient(90deg, transparent 0.8rem, skyblue 0.8rem) left/2.4rem 100%;
  background: -webkit-linear-gradient(90deg, transparent 0.8rem, skyblue 0.8rem) left/2.4rem 100%;
  background: -o-linear-gradient(90deg, transparent 0.8rem, skyblue 0.8rem) left/2.4rem 100%;
  background: -ms-linear-gradient(90deg, transparent 0.8rem, skyblue 0.8rem) left/2.4rem 100%;
  background: linear-gradient(90deg, transparent 0.8rem, skyblue 0.8rem) left/2.4rem 100%;
  height: 40%;
  position: absolute;
  top: 0.7rem;
  width: 100%;}.compartment-window::before, .compartment-window::after {
  content: "";
  position: absolute;}.compartment-window::before {
  animation: up-down 0.3s 0.1s infinite;
  background: #104b63;
  border-radius: 50% 50% 0 0;
  height: 0.6rem;
  left: 50%;
  top: -1.4rem;
  transform: translate(-50%, 0);
  width: 110%;}

So far, we have used HTML and CSS codes to draw the entire train and the surrounding environment.

The most important step is to make this little train run on the bridge. This requires the use of some animation properties of CSS3. CSS3 animation frames make a debut.

@keyframes up-down {
  0%, 100% {
    transform: translate(-50%, 0);
  }
  50% {
    transform: translate(-50%, -0.3rem);
  }}@keyframes rotate {
  100% {
    transform: rotate(-360deg);
  }}@keyframes move-train {
  100% {
    transform: translateX(-154rem);
  }}@keyframes body-upDown {
  0%, 100% {
    transform: translateY(0);
  }
  100% {
    transform: translateY(-0.2rem);
  }}@keyframes move-smoke {
  0% {
    -webkit-filter: blur(0);
    -moz-filter: blur(0);
    -o-filter: blur(0);
    -ms-filter: blur(0);
    filter: blur(0);
    opacity: 1;
  }
  50% {
    -webkit-filter: blur(0.2rem);
    -moz-filter: blur(0.2rem);
    -o-filter: blur(0.2rem);
    -ms-filter: blur(0.2rem);
    filter: blur(0.2rem);
    opacity: 0.6;
    transform: translate(0, -3rem) scale(2);
  }
  100% {
    -webkit-filter: blur(0.3rem);
    -moz-filter: blur(0.3rem);
    -o-filter: blur(0.3rem);
    -ms-filter: blur(0.3rem);
    filter: blur(0.3rem);
    opacity: 0;
    transform: translate(2.5rem, -6rem) scale(3);
  }}@keyframes wheel-joint {
  100% {
    transform: rotate(360deg);
  }}

Several things have been done in these animations:

Let the carriage lid flap up and down to make the animated train look more realistic.
Using filters, the steam emitted from the steam engine as the train is moving is vividly depicted.
Let the small train run over and over the bridge as a whole, and the wheels keep turning.
At this point, the entire animation of the train is basically completed. At the end of the article, the source code is also dedicated to everyone.
