Is the Category 6e cable marked 6e or 6a?

The Category 6e network cable mark is 6a, and its complete logo is CAT6A; CAT6E is an improved version of CAT6, but not CAT6A; Category 6e network cables and Category 6 network cables generally have insulation added to their internal structures. Cross skeleton, and 4 pairs of twisted pairs are arranged in the 4 grooves of the cross skeleton. However, the cross skeleton inside the Category 6e network cable generally uses a gear-shaped wire groove shape, while the cross skeleton of the Category 6 network cable They are usually separated by one word.

#The operating environment of this tutorial: Windows 7 system, Dell G3 computer.

Is the Category 6e cable marked 6e or 6a?

The mark on the sheath of Category 6 network cable is CAT6, and the mark on the sheath of Category 6e network cable is CAT6A. Note that it is not CAT6E. CAT6E (Category 6) is an improved version of CAT6 (Category 6). But not CAT6A (Category 6A).

The internal structure of Category 6e network cables and Category 6 network cables generally adds a cross skeleton with insulating effect, and four pairs of twisted pairs are arranged in the cross Within the four grooves of the skeleton, the cross skeleton inside the Category 6e network cable generally uses a gear-shaped cable trough shape, while the cross skeleton of the Category 6 network cable is generally isolated in one line.

Note:

Since the outer diameter of Category 6 cable is thicker than that of general Category 5 cable, in order to avoid the entanglement of the cable (especially At the elbow), when designing the pipeline, we must pay attention to the filling degree of the pipe diameter. Generally, it is appropriate to put two Category 6 wires in a pipe with an inner diameter of 20mm.

The bridge is designed reasonably to ensure appropriate cable bending radius. When going up, down, left, and right around other wire troughs, the turning slope should be gentle. Pay attention to whether the cover can be covered without damaging the cable after the cables at both ends are drooped and stressed.

During the pay-out process, the main thing is to pay attention to the control of the tension. For cables packaged with reels, it is recommended to arrange at least one worker at each end to put the reel on the homemade pull rod. The worker at the pay-out end first Pre-pull a part of the cable from the reel box for the collaborator to extract at the other end of the pipeline. The pre-pulled wire should not be too much to avoid multiple wires getting tangled and wrapped around the venue.
