What kind of phone is oppo's 240w fast charger?

oppo’s 240W fast charging is an engineering test machine; oppo has released 240W super flash charging technology, which can fully charge a 4500mAh battery in 9 minutes. However, this technology has not yet been officially put into commercial use. 240W super flash charging is available in adapters, The entire charging link of wires and batteries ensures temperature control and safety, greatly reducing heat generation. It adopts a dual "Type-C" interface solution and is compatible with more fast charging protocols.

The operating environment of this tutorial: ColorOS 12 system, OPPO Find X5 Pro mobile phone.

What kind of mobile phone does oppo’s 240w fast charge mean?

OPPO has released 240W super flash charging technology, which can charge a 4500mAh battery to 100% in 9 minutes. 240W super flash charging can be used in adapters, wires, The entire battery charging link ensures temperature control and safety, greatly reducing heat generation, "cool" flash charging throughout the entire process, and a dual Type-C interface solution that is compatible with more fast charging protocols.

Expand knowledge

At MWC 2022 Barcelona World Mobile Communications Conference, OPPO officially released the longevity version 150W Super flash charging and 240W super flash charging have once again refreshed the commercial fast charging speed record for mobile phones. Especially the 240W super flash charging technology, which is already several times the 65W commonly used power in notebooks, and it simply subverts all views.

In the past few years, the charging power of mobile phones has increased from 10W to 100W. The power increase has reached ten times. While everyone is competing to enter the 100-watt club, OPPO has chosen to maintain 65W for two years. , until today, I finally came up with the big move - 240W super flash charging.

The 240W super flash charge does not choose the USB-A port system that OPPO has used for flash charging in the past, but uses a more universal USB-C charger. The output parameter is 24V10A, which is directly output by two charge pumps. to the dual string battery pack. After entering the mobile phone, the power is converted into 10V/24A through a charge pump for high-voltage direct charging. The new generation of battery cells supports higher rate charging, and the current of a single battery cell can reach 12A. 240W super flash charging can charge a mobile phone with an equivalent battery capacity of 4500mAh to 100% in 9 minutes.

While breaking through the charging speed limit, OPPO has not sacrificed safety. OPPO has customized a USB-C connector with lower impedance to further reduce contact resistance, and uses thicker wire cores to enable high-current and high-power power transmission. The terminal is also equipped with an E-Marker encryption chip, and the encryption algorithm eliminates security risks such as hacker firmware.

240W super flash charging has five layers of security protection from the power adapter, wires, and mobile phone. The mobile phone is equipped with 13 temperature sensors and has a specially customized intelligent control chip with full line control, voltage control, flow control, and temperature control. Provide all-round security.
