How to fill color in CAD graphics

coldplay.xixi
coldplay.xixiOriginal
2021-02-04 14:28:18118686browse

How to fill color in cad graphics: first open the file to be filled with color, and press the H plus space shortcut key; then select the gradient color option, and pick the graphic that needs to be filled with color; finally click OK.

How to fill color in CAD graphics

The operating environment of this article: Windows 7 system, autocad2020 version, Dell G3 computer.

How to fill color in cad graphics:

1. Find the CAD file that needs to be filled with color on the desktop, and double-click to open it.

How to fill color in CAD graphics

#2. Find and click the fill pattern and color change command symbols in the drawing command, or press H plus the space shortcut key in English mode, the fill pattern and color will pop up. Shame discolored dialog box.

How to fill color in CAD graphics

3. In the pop-up pattern fill and gradient color dialog box, select the gradient color option, select the appropriate color in the color option, and select the appropriate color in the coloring to a lighter contrast, then add a plus sign in front of the pick point with a Border selection.

How to fill color in CAD graphics

#4. Click once on the graphic that needs to be filled with color to pick it up.

How to fill color in CAD graphics

#5. After picking up the graphic, right-click to confirm, and the pattern fill and gradient dialog box will pop up. At this time, just click OK in the lower left corner. .

How to fill color in CAD graphics

#6. Finally, check the color you filled to see if the rendering effect is satisfactory.

How to fill color in CAD graphics
