How to use CAD angle annotation

How to use CAD angle annotation: 1. Select the triangle shape, click the angle annotation in the annotation, or enter the DIMANGULAR command space; 2. If you want to annotate that angle, select the diagonal of the angle and click the angle. Label.

The operating environment of this article: Windows 7 system, autocad2020 version, Dell G3 computer.

How to use CAD angle marking:

1. For example, how to mark the angle of a triangular figure.

#2. Click the angle mark in the mark, or enter the DIMANGULAR command with a space to mark.

#3. If you want to mark that corner, just choose the diagonal line of the corner.

#4. In this way, the angle is marked, and then click on the location.

#5. Mark the other corners in the same way.
