Django+Layui background layout introduction

Layui background layout:

1. Top sidebar of background layout

<div class="layui-header">
        <div class="layui-logo">layui 后台布局</div>
        <!-- 头部区域（可配合layui已有的水平导航） -->
        <ul class="layui-nav layui-layout-left">
            <li class="layui-nav-item"><a href="">控制台</a></li>
            <li class="layui-nav-item"><a href="">商品管理</a></li>
            <li class="layui-nav-item"><a href="">用户</a></li>
            <li class="layui-nav-item">
                <a href="javascript:;">其它系统</a>
                <dl class="layui-nav-child">
                    <dd><a href="">邮件管理</a></dd>
                    <dd><a href="">消息管理</a></dd>
                    <dd><a href="">授权管理</a></dd>
                </dl>
            </li>
        </ul>
        <ul class="layui-nav layui-layout-right">
            <li class="layui-nav-item">
                <a href="javascript:;">
                    <img  class="layui-nav-img lazy"  src="/static/imghwm/default1.png"  data-src="http://t.cn/RCzsdCq"    alt="Django+Layui background layout introduction" >
                    {{request.user.username}}
                </a>
                <dl class="layui-nav-child">
                    <dd><a href="">基本资料</a></dd>
                    <dd><a href="">安全设置</a></dd>
                </dl>
            </li>
            <li class="layui-nav-item"><a href="">退了</a></li>
        </ul>
    </div>

The line with orange background in the code is the current login passed in Django The user's username.

The final effect is as follows:

2. Sidebar of background layout

The sidebar needs to dynamically load nodes and sub-nodes. Therefore, you need to first establish the model of nodes and sub-nodes in Django. The model code is as follows:

# 节点类
class NavigationProfile(models.Model):
    name=models.CharField(max_length=20,verbose_name='节点名称')
    url=models.CharField(max_length=50,verbose_name='链接地址')
    iconCls=models.CharField(max_length=50,verbose_name='图标icon')

    class Meta:
        verbose_name='节点名称'
        verbose_name_plural=verbose_name

    def __str__(self):
        return self.name

# 子节点类
class NavigationSubProfile(models.Model):
    name=models.CharField(max_length=20,verbose_name='子节点名称')
    url=models.CharField(max_length=50,verbose_name='链接地址')
    iconCls=models.CharField(max_length=50,verbose_name='图标icon')
    parent=models.ForeignKey(NavigationProfile,on_delete=models.CASCADE,verbose_name='父节点')

    class Meta:
        verbose_name='子节点名称'
        verbose_name_plural=verbose_name

    def __str__(self):
        return self.name

The code in Django views is as follows:

def open_index(request):
    if request.user.is_authenticated == False:
        return HttpResponseRedirect('/account/login/')
    else:
        navigation = NavigationProfile.objects.all()
        dict = []

        for nav in navigation:
            dic = {}
            id = nav.id
            dic['id'] = nav.id
            dic['text'] = nav.name
            dic['url'] = nav.url
            dic['iconCls'] = nav.iconCls
            dic['nid'] = 0
            sub_navigation = NavigationSubProfile.objects.filter(parent_id=id)

            sub_dict = []
            for sub_nav in sub_navigation:
                sub_dic = {}
                sub_dic['id'] = sub_nav.id
                sub_dic['text'] = sub_nav.name
                sub_dic['url'] = sub_nav.url
                sub_dic['iconCls'] = sub_nav.iconCls
                sub_dic['nid'] = sub_nav.parent_id
                sub_dict.append(sub_dic)

            dic["children"] = sub_dict
            dict.append(dic)30         return render(request,'index.html',{'dict':dict})

The Django urls code is as follows:

 urlpatterns = [
     path('get-navigationProfile/',views.get_navigationProfile,name='get_navigationProfile'),
 ]

The Html sidebar code is as follows:

<div class="layui-side layui-bg-black">
        <div class="layui-side-scroll">
            <!-- 左侧导航区域（可配合layui已有的垂直导航） -->
            <ul class="layui-nav layui-nav-tree" lay-filter="test">

                {% for dic in dict %}
                    <li class="layui-nav-item">
                        <a class="" href="javascript:;">{{ dic.text }}</a>
                        <dl class="layui-nav-child">
                            {% for child in dic.children %}
                                <dd><a href="javascript:;" data-id="{{ child.id }}"
                                       data-url="{{ child.url }}">{{ child.text }}</a></dd>
                            {% endfor %}

                        </dl>
                    </li>
                {% endfor %}

            </ul>
        </div>
    </div>

Final rendering

For more layui knowledge, please pay attention to the layui usage tutorial column.
